SECTION 6
[CHASSIS UNIT]
REF. ORDER
NO. NO.
J1 6510000370 Antenna connector MR-DS
W7 8900011980 Cable OPC-1214
W8 8900011980 Cable OPC-1214
W9 8900011970 Cable OPC-1213
EP1 880001250 DSP unit UT-106 [Equipped version] only
SP1 2510000990 Speaker VS-66Y0811
MP1 8010001490 Stand (D)
MP2 8930005790 Color foot (A)
MP3 8930005800 Color foot (B)
Flange bolt M4 × 8 NI
MP4 8820000530
MP5 8930042690 Rubber foot (L)
MP8 8930052450 2355 earth plate
Screw PH BT M3 × 8 NI-ZU
MP9 8810008660
Screw PH BT M3 × 8 NI-ZU
MP10 8810008660
Screw FH M2.6 × 6 ZK
MP11 8810009610
MP12 8850000140 Flat washer M4 NI BS
Screw BT M2 × 10 ZK
MP13 8810008990
MP14 8850001560 Ster washer M4
Screw PH BT M3 × 8 NI-ZU
MP15 8810008660
Screw PH M3 × 6 ZK
MP16 8810004430
Screw PH M3 × 6 ZK
MP17 8810004430
Setscrew C M3 × 10
MP19 8810003380
Screw FH M2.6 × 6 ZK
MP20 8810009610
MP21 8930042440 1897 SP holder
Screw FH M2.6 × 6 ZK
MP22 8810009610
MP23 8010019121 2591 chassis-1
MP24 8110007880 2591 L-cover
MP25 8110007940 2591 T-cover assembly
MP26 8930059121 Thermally sheet (AJ)-1
MP28 8930059971 2591 A-sponge-1
MP29 8930059961 2591 SP sponge-1
MP30 8930059880 Earth spring (H)
Screw PH BT M3 × 8 NI-ZU
MP32 8810008660
MP33 8510015060 2591 shield plate
MP35 8930060140 Sheet (CI)
MP36 8930060140 Sheet (CI)
MP38 8930060310 Shield tape (P)
MP39 8930060300 Shield tape (O)
MP40 8930060290 Shield tape (N)

MECHANICAL PARTS AND DISASSEMBLY

DESCRIPTION QTY.
[FRONT UNIT]
REF. ORDER
NO. NO.
1 EP1 0880001360
1 W1 8900006040
1 W2 8900006251
1
MP1 8210019400
1 MP2 8210012580
MP3 8930058960
1 MP4 8930047960
MP7 8930036751
1 MP9 8830001010
1 MP10 8610010000
1 MP11 8610010010
1 MP12 8610010112
2 MP15 8930036691
1 MP18 8310036273
9 MP19 8950004192
2 MP20 8930036740
9 MP21 8930037111
1 MP23 8810008990
1 MP24 8930038940
1 MP26 8610010360
9 MP27 8610007510
2 MP28 8610007510
2
2

[DISPLAY BOARD]

9
1
REF. ORDER
4
NO. NO.
1
J2 6450001630
1
1
DS4 5030001670
2
DS5 5030002560
1
1
EP7 8930059720
1
1
MP1 8930036710
1
MP2 8810009040
1
MP3 8830000180
1
MP4 8510015220
1
MP6 8510014100
1
1
6 - 1
DESCRIPTION
EX-2500 #02
Flat cable OPC-593
Cable OPC-610A
2177 front panel (A)-1 assembly
1691 rear panel
2177 menu key (A)
2177 mode key
Spring (Y)-1
Hex nut (A)
Knob N237 (incl. MP28)
Knob N238
Knob N239-2 assembly
1691 release button-1
1691 brake plate-3 (incl. MP20)
1691 contact base (B)-2
1691 brake pad
1691 brake sheet-1
Screw PH BT M2 × 10 ZK
Sponge (EF)
Knob N260 (incl. MP27)
Knob spring No.7800
Knob spring No.7800
DESCRIPTION
Connector HSJ1406-01-050 (PHONES)
LCD DLC-8309YBGF
LED CV1073
LCD connector SRCN-2591-SP-N-W
1691 LCD holder
Setscrew H M2.6 × 10 NI
Nut M2.6 NI BS
2591 front plate
2177 front shield
QTY.
1
1
1
1
1
1
1
1
2
1
2
1
1
1
1
2
1
2
1
1
1
1
QTY.
1
1
1
2
1
1
1
1
1
