Icom IC-703 Service Manual page 43

[MAIN UNIT]
REF ORDER
NO. NO.
L6804 6180003290 COIL
L6828 6910003570 COIL
L6951 6180003290 COIL
L6953 6180003290 COIL
L6954 6140002220 COIL
L6962 6180003290 COIL
L6963 6140002220 COIL
L7351 6180003290 COIL
L7371 6180003290 COIL
L7373 6180003290 COIL
L9021 6200005010 S.COIL
L9022 6200005010 S.COIL
L9051 6200004960 S.COIL
L9052 6200003120 S.COIL
L9053 6200004960 S.COIL
L9101 6200005050 S.COIL
L9151 6200008910 S.COIL
L9201 6200008910 S.COIL
L9202 6190001280 COIL
L9203 6200008910 S.COIL
L9251 6200008910 S.COIL
L9252 6190001600 COIL
L9253 6200008910 S.COIL
L9301 6200004960 S.COIL
L9401 6200002410 S.COIL
L9402 6200002420 S.COIL
L9403 6200002420 S.COIL
L9404 6200002840 S.COIL
L9521 6200002000 S.COIL
L9522 6200004670 S.COIL
L9523 6200005010 S.COIL
L9524 6200005010 S.COIL
L9525 6200005010 S.COIL
L9621 6200008910 S.COIL
L9622 6190001280 COIL
L9623 6180003290 COIL
L9624 6200008910 S.COIL
L9651 6200007790 S.COIL
L9672 6200002180 S.COIL
L9751 6200003240 S.COIL
L9960 6140002220 COIL
R1 7030003320 S.RESISTOR
R2 7030003380 S.RESISTOR
R3 7030003290 S.RESISTOR
R4 7030003720 S.RESISTOR
R5 7030003360 S.RESISTOR
R6 7030003720 S.RESISTOR
R7 7030003440 S.RESISTOR
R8 7030003640 S.RESISTOR
R9 7030003440 S.RESISTOR
R10 7030003640 S.RESISTOR
R11 7030003360 S.RESISTOR
R101 7030003370 S.RESISTOR
R102 7030003230 S.RESISTOR
R103 7030003370 S.RESISTOR
R104 7030003200 S.RESISTOR
R105 7030003720 S.RESISTOR
R106 7030003350 S.RESISTOR
R201 7030003400 S.RESISTOR
R202 7030003320 S.RESISTOR
R203 7030003310 S.RESISTOR
R204 7030003320 S.RESISTOR
R205 7030003370 S.RESISTOR
R206 7030003720 S.RESISTOR
R305 7030003720 S.RESISTOR
R306 7030003720 S.RESISTOR
R401 7030003440 S.RESISTOR
R402 7030003560 S.RESISTOR
R403 7030003560 S.RESISTOR
R404 7030003560 S.RESISTOR
R405 7030003560 S.RESISTOR
R406 7030003560 S.RESISTOR
R407 7030003560 S.RESISTOR
R408 7030003560 S.RESISTOR
R409 7030003560 S.RESISTOR
R411 7030003440 S.RESISTOR
A: [EUR], [EUR-1], [USA], [USA-1], [KOR], [KOR-1]
C: [FRA], [FRA-1], [ITA], [ITA-1]
E: [FRA], [FRA-1], [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1]
DESCRIPTION
BM27-400-6A
2943-666663
BM27-400-6A
BM27-400-6A
LR-270 (TR6X3X2 3A9)
BM27-400-6A
LR-270 (TR6X3X2 3A9)
BM27-400-6A
BM27-400-6A
BM27-400-6A
NL 252018T-100J
NL 252018T-100J
NL 252018T-R33J
NL 322522T-8R2J
NL 252018T-R33J
NL 252018T-330J
1812CS-122XKBC
1812CS-122XKBC
E544GN-110248
1812CS-122XKBC
A only
1812CS-122XKBC
A only
E544GN-110275
A only
1812CS-122XKBC
NL 252018T-R33J
NL 252018T-056J
NL 252018T-068J
NL 252018T-068J
NL 252018T-R22J
NL 252018T-3R3J
NL 252018T-3R9J
NL 252018T-100J
NL 252018T-100J
NL 252018T-100J
1812CS-122XKBC
E544GN-110248
BM27-400-6A
1812CS-122XKBC
LQW2BHNR15J01L
NL 252018T-R12J
NL 322522T-221J
LR-270 (TR6X3X2 3A9)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 560 V (56 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 180 V (18 Ω)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 181 V (180 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 820 V (82 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
A only
ERJ3GEYJ 103 V (10 kΩ)
A only
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
[MAIN UNIT]
REF ORDER
NO. NO.
R412 7030003440 S.RESISTOR
R413 7030003440 S.RESISTOR
R415 7030003640 S.RESISTOR
R416 7030003640 S.RESISTOR
R417 7030003640 S.RESISTOR
R501 7030003390 S.RESISTOR
R502 7030003280 S.RESISTOR
R503 7030004050 S.RESISTOR
R504 7030003280 S.RESISTOR
R505 7030003370 S.RESISTOR
R521 7030003390 S.RESISTOR
R522 7030003400 S.RESISTOR
R523 7030003720 S.RESISTOR
R541 7030003380 S.RESISTOR
R542 7030003370 S.RESISTOR
R543 7030003720 S.RESISTOR
R551 7030003380 S.RESISTOR
R552 7030003370 S.RESISTOR
R553 7030003720 S.RESISTOR
R561 7030003380 S.RESISTOR
R562 7030003370 S.RESISTOR
R563 7030003720 S.RESISTOR
R571 7030003380 S.RESISTOR
R572 7030003370 S.RESISTOR
R573 7030003720 S.RESISTOR
R581 7030003380 S.RESISTOR
R582 7030003370 S.RESISTOR
R583 7030003720 S.RESISTOR
R591 7030003380 S.RESISTOR
R592 7030003370 S.RESISTOR
R593 7030003720 S.RESISTOR
R601 7030003720 S.RESISTOR
R602 7030003720 S.RESISTOR
R621 7030003720 S.RESISTOR
R622 7030003720 S.RESISTOR
R623 7030003360 S.RESISTOR
R624 7030003360 S.RESISTOR
R631 7030003320 S.RESISTOR
R632 7030003290 S.RESISTOR
R633 7030003320 S.RESISTOR
R634 7030003720 S.RESISTOR
R635 7030003720 S.RESISTOR
R651 7030003280 S.RESISTOR
R652 7030003440 S.RESISTOR
R653 7030003520 S.RESISTOR
R654 7030003720 S.RESISTOR
R655 7030003240 S.RESISTOR
R701 7030003360 S.RESISTOR
R702 7030003440 S.RESISTOR
R703 7030003440 S.RESISTOR
R704 7030003640 S.RESISTOR
R752 7030003590 S.RESISTOR
R753 7030003420 S.RESISTOR
R754 7030004040 S.RESISTOR
R755 7030003220 S.RESISTOR
R756 7030003580 S.RESISTOR
R757 7030003360 S.RESISTOR
R758 7030003440 S.RESISTOR
R759 7030003640 S.RESISTOR
R771 7030003370 S.RESISTOR
R772 7030003230 S.RESISTOR
R773 7030003370 S.RESISTOR
R801 7030003440 S.RESISTOR
R802 7030003280 S.RESISTOR
R811 7030003440 S.RESISTOR
R812 7030003280 S.RESISTOR
R813 7030003320 S.RESISTOR
R831 7030003440 S.RESISTOR
R832 7030003320 S.RESISTOR
R833 7310002740 S.TRIMMER
R834 7510001460 S.THERMISTOR NTCG16 3NH 471KT
R835 7030003340 S.RESISTOR
R836 7030003470 S.RESISTOR
R837 7030003550 S.RESISTOR
R838 7030003440 S.RESISTOR
R839 7030003410 S.RESISTOR
R840 7030003360 S.RESISTOR
R841 7510001460 S.THERMISTOR NTCG16 3NH 471KT
B: [EUR], [EUR-1], [ESP], [ESP-1], [OTH], [OTH-1]
D: [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1]
F: [FRA], [FRA-1], [ESP], [ESP-1], [OTH], OTH-1], [ITA], [ITA-1]
5 - 12
DESCRIPTION
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 391 V (390 Ω)
A only
ERJ3GEYJ 470 V (47 Ω)
A only
ERJ3GEYJ 1R0 V (1 Ω)
A only
ERJ3GEYJ 470 V (47 Ω)
A only
ERJ3GEYJ 271 V (270 Ω)
A only
ERJ3GEYJ 391 V (390 Ω)
A only
ERJ3GEYJ 471 V (470 Ω)
A only
ERJ3GEYJ 224 V (220 kΩ) A only
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 560 V (56 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 220 V (22 Ω)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 4R7 V (4.7 Ω)
ERJ3GEYJ 150 V (15 Ω)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 180 V (18 Ω)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 101 V (100 Ω)
RV-150 (RH03A3A14X0FC) 103
ERJ3GEYJ 151 V (150 Ω)
ERJ3GEYJ 182 V (1.8 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 561 V (560 Ω)
ERJ3GEYJ 221 V (220 Ω)
S.=Surface mount
