Icom IC-703 Service Manual page 34

[PA UNIT]
REF ORDER
NO. NO.
IC1 1180002010 S.REG
IC560 1110002700 S.IC
IC600 1140010671 S.IC
IC601 1130006800 S.IC
IC640 1110001590 S.IC
IC641 1130005640 S.IC
Q80 1560001260 S.FET
Q81 1560001220 S.FET
Q101 1560001100 S.FET
Q150 1560001240 S.FET
Q200 1560001230 S.FET
Q201 1560001230 S.FET
Q250 1560001260 S.FET
Q300 1530003090 S.TRANSISTOR 2SC4213-B (TE85R)
Q400 1560001250 S.FET
Q401 1560001250 S.FET
Q420 1560001250 S.FET
Q421 1560001250 S.FET
Q440 1560001250 S.FET
Q441 1560001250 S.FET
Q460 1560001250 S.FET
Q461 1560001250 S.FET
Q480 1560001250 S.FET
Q481 1560001250 S.FET
Q500 1560001250 S.FET
Q501 1560001250 S.FET
Q520 1560001250 S.FET
Q521 1560001250 S.FET
Q602 1510000500 S.TRANSISTOR 2SA1162-GR (TE85R)
Q603 1560001260 S.FET
Q640 1560001260 S.FET
Q641 1560000560 S.FET
Q642 1560001260 S.FET
Q643 1560000560 S.FET
Q644 1590001330 S.TRANSISTOR DTA114EUA T106
Q645 1560001260 S.FET
Q646 1560001260 S.FET
Q700 1560001250 S.FET
Q701 1560001250 S.FET
Q702 1560001250 S.FET
Q703 1560001250 S.FET
Q704 1560001250 S.FET
Q705 1560001250 S.FET
Q706 1560001250 S.FET
Q707 1560001250 S.FET
Q708 1560001250 S.FET
Q709 1560001250 S.FET
Q800 1560001250 S.FET
Q801 1560001250 S.FET
Q802 1560001250 S.FET
Q803 1560001250 S.FET
Q804 1560001250 S.FET
Q805 1560001250 S.FET
Q806 1560001250 S.FET
Q807 1560001250 S.FET
Q808 1560001250 S.FET
Q809 1560001250 S.FET
Q810 1560001250 S.FET
Q811 1530002570 S.TRANSISTOR 2SC4405-3-TL
Q900 1560001220 S.FET
Q902 1560001260 S.FET
D80 1790000700 DIODE
D250 1750000550 S.DIODE
D300 1750000850 S.DIODE
D400 1160000070 S.DIODE
D401 1160000070 S.DIODE
D420 1160000070 S.DIODE
D421 1160000070 S.DIODE
D440 1160000070 S.DIODE
D441 1160000070 S.DIODE
D460 1160000070 S.DIODE
D461 1160000070 S.DIODE
D480 1160000070 S.DIODE
D481 1160000070 S.DIODE
A: [EUR], [EUR-1], [USA], [USA-1], [KOR], [KOR-1]
C: [FRA], [FRA-1], [ITA], [ITA-1]
E: [FRA], [FRA-1], [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1]
DESCRIPTION
BA08FP-E2
NJM2904M-TE1
ISPLSI2064VE-100LT100 I002
TC7W08F (TE12L)
TA75393F (TP1)
TC4W53F (TE12L)
2SK3018 T106
ECH8301-TL
2SK3074 (TE12L)
RD01MUS1
RD07MVS1
RD07MVS1
2SK3018 T106
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
A only
UM5KIN-TR
A only
UM5KIN-TR
2SK3018 T106
2SK3018 T106
2SK882-GR (TE85L)
2SK3018 T106
2SK882-GR (TE85L)
2SK3018 T106
2SK3018 T106
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
UM5KIN-TR
ECH8301-TL
2SK3018 T106
DSA3A1
1SS355 TE-17
MMBV3700LT1
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
[PA UNIT]
REF ORDER
NO. NO.
D500 1160000070 S.DIODE
D501 1160000070 S.DIODE
D520 1160000070 S.DIODE
D521 1160000070 S.DIODE
D560 1750000950 S.DIODE
D561 1750000950 S.DIODE
D562 1750000950 S.DIODE
D563 1750000950 S.DIODE
D640 1790001790 S.DIODE
D641 1750000550 S.DIODE
D642 1750000370 S.DIODE
D643 1750000430 S.DIODE
D644 1790001250 S.DIODE
D645 1790001790 S.DIODE
D646 1790001790 S.DIODE
D647 1750000550 S.DIODE
D750 1160000070 S.DIODE
D751 1160000070 S.DIODE
D752 1160000070 S.DIODE
D753 1160000070 S.DIODE
D754 1160000070 S.DIODE
D755 1160000070 S.DIODE
D756 1160000070 S.DIODE
D757 1160000070 S.DIODE
D758 1160000070 S.DIODE
D759 1160000070 S.DIODE
D850 1160000070 S.DIODE
D851 1160000070 S.DIODE
D852 1160000070 S.DIODE
D853 1160000070 S.DIODE
D854 1160000070 S.DIODE
D855 1160000070 S.DIODE
D856 1160000070 S.DIODE
D857 1160000070 S.DIODE
D858 1160000070 S.DIODE
D859 1160000070 S.DIODE
D860 1160000070 S.DIODE
L1 6200005010 S.COIL
L2 6200001830 S.COIL
L3 2040000490 COIL
L5 6200003030 S.COIL
L80 2040000490 COIL
L81 2040000490 COIL
L82 2040000490 COIL
L100 6200002640 S.COIL
L101 6200002040 S.COIL
L151 6200003950 S.COIL
L153 6140002350 COIL
L200 6150005310 COIL
L201 2040000490 COIL
L202 2040000490 COIL
L203 6110001630 COIL
L250 6200005010 S.COIL
L300 6110001560 COIL
L301 6110001640 COIL
L400 6150005180 COIL
L401 6150005190 COIL
L402 6200001720 S.COIL
L420 6150005200 COIL
L421 6150005210 COIL
L440 6150005220 COIL
L441 6150005230 COIL
L442 6150005230 COIL
L460 6150005250 COIL
L461 6150005240 COIL
L480 6150005280 COIL
L481 6150005260 COIL
L500 6150005270 COIL
L501 6150005270 COIL
L520 6110001640 COIL
L521 6110001650 COIL
L522 6110001650 COIL
L540 6200001720 S.COIL
L560 6140003490 COIL
L640 6140002810 S.COIL
L641 6140002810 S.COIL
B: [EUR], [EUR-1], [ESP], [ESP-1], [OTH], [OTH-1]
D: [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1]
F: [FRA], [FRA-1], [ESP], [ESP-1], [OTH], OTH-1], [ITA], [ITA-1]
5 - 3
DESCRIPTION
DAN202K T146
DAN202K T146
A only
DAN202K T146
A only
DAN202K T146
MA732 (TX)
MA732 (TX)
MA732 (TX)
MA732 (TX)
RB876W TL
1SS355 TE-17
DA221 TL
HSB88WSTR
MA2S111-(TX)
RB876W TL
RB876W TL
1SS355 TE-17
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
DAN202K T146
NL 252018T-100J
NL 322522T-100J
EXC-ELDR25C
NL 322522T-R47J-3
EXC-ELDR25C
EXC-ELDR25C
EXC-ELDR25C
NL 252018T-R15J
NL 252018T-101J
HF50ACC 322513-T
LR-274 (RIB4X7X5 3A6)
LR-430
EXC-ELDR25C
EXC-ELDR25C
LA-246
NL 252018T-100J
LA-236
LA-247
LR-417
LR-418
NL 322522T-1R0J
LR-419
LR-420
LR-421
LR-422
LR-422
LR-424
LR-423
LR-427
LR-425
LR-426
LR-426
A only
LA-247
A only
LA-248
A only
LA-248
NL 322522T-1R0J
LR-391
LR-317
LR-317
S.=Surface mount
