Parts List; Vr Unit; Jack Unit; Display Unit - Icom IC-703 Service Manual

SECTION 5

[VR UNIT]

REF ORDER
NO. NO.
R1 7210002780 VARIABLE
R2 7210002940 VARIABLE
J1 6510018890 S.CONNECTOR 52559-1390
S1 2220000540 SWITCH
EP1 0910055780 PCB

[JACK UNIT]

REF ORDER
NO. NO.
J1 6510023460 S.CONNETOR
EP1 0910055741 PCB
[FRONT UNIT]
REF ORDER
NO. NO.
W1 8900006040 CABLE
W2 8900006251 CABLE
EP1 0880001360 UNIT BOARD

[DISPLAY UNIT]

REF ORDER
NO. NO.
IC2 1130007960 S.IC
IC3 1130008130 S.IC
IC4 1110005780 S.IC
IC5 1110005760 S.IC
IC6 1140011250 S.IC
Q1 1590002310 S.TRANSISTOR DTC114EE TL
Q2 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q3 1530002060 S.TRANSISTOR 2SC4081 T106 R
Q4 1560001290 S.FET
Q10 1530002060 S.TRANSISTOR 2SC4081 T106 R
Q11 1520000380 TRANSISTOR
Q12 1590002370 S.TRANSISTOR XP4111 (TX)
Q13 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q14 1530002060 S.TRANSISTOR 2SC4081 T106 R
Q15 1590001870 S.TRANSISTOR DTA114EE TL
Q16 1590002770 S.FET
Q18 1590002370 S.TRANSISTOR XP4111 (TX)
Q50 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q51 1530002060 S.TRANSISTOR 2SC4081 T106 R
A: [EUR], [EUR-1], [USA], [USA-1], [KOR], [KOR-1]
C: [FRA], [FRA-1], [ITA], [ITA-1]
E: [FRA], [FRA-1], [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1]

PARTS LIST

DESCRIPTION
RV-300 (RK0972210) 10KB/10KB
TP96D231E20-20F-10KB-1897
SW-162 (SSSS22-2-11)
B 5913
DESCRIPTION
08FMN-BMTTR-A-TBT
B 5915A
DESCRIPTION
OPC-593 (N:13 L:50)
OPC-610A
EX-2500 #02
DESCRIPTION
SED1522F0C (QFP15-100PIN)
TC7W32FU (TE12L)
S-80945CLMC-G7F-T2
S-812C50AUA-C3E-T2
HD6473847RH (SX-2591C)
2SK3065 T100
2SB1143 S
CPH3404-TL
[DISPLAY UNIT]
REF ORDER
NO. NO.
D1 1750000370 S.DIODE
D2 1750000370 S.DIODE
D3 1750000370 S.DIODE
D5 1790001250 S.DIODE
D6 1790001250 S.DIODE
D7 1160000140 S.DIODE
D9 1790001250 S.DIODE
D10 1790001250 S.DIODE
D11 1750000520 S.DIODE
D12 1790001250 S.DIODE
D13 1750000520 S.DIODE
D14 1160000140 S.DIODE
D15 1160000140 S.DIODE
D16 1160000140 S.DIODE
D50 1750000520 S.DIODE
D51 1790001250 S.DIODE
X1 6050009870 S.XTAL
L1 6200003260 S.COIL
L2 6200003950 S.COIL
L3 6200003950 S.COIL
L4 6200003950 S.COIL
L5 6200003950 S.COIL
L29 6200003520 S.COIL
L30 6200008420 S.COIL
L31 6200008420 S.COIL
R2 7030003400 S.RESISTOR
R3 7030003400 S.RESISTOR
R4 7030003440 S.RESISTOR
R5 7030003340 S.RESISTOR
R6 7030003440 S.RESISTOR
R7 7030003440 S.RESISTOR
R8 7030003590 S.RESISTOR
R9 7030003560 S.RESISTOR
R10 7030003590 S.RESISTOR
R11 7030003560 S.RESISTOR
R12 7030003590 S.RESISTOR
R13 7030003560 S.RESISTOR
R14 7030003590 S.RESISTOR
R15 7030003560 S.RESISTOR
R16 7030003590 S.RESISTOR
R17 7030003560 S.RESISTOR
R18 7030003590 S.RESISTOR
R19 7030003560 S.RESISTOR
R20 7030003560 S.RESISTOR
R21 7030003560 S.RESISTOR
R22 7030003560 S.RESISTOR
R23 7030003560 S.RESISTOR
R24 7030003560 S.RESISTOR
R25 7030003560 S.RESISTOR
R26 7030003520 S.RESISTOR
R27 7030003520 S.RESISTOR
R29 7030003520 S.RESISTOR
R30 7030003440 S.RESISTOR
R33 7030006190 S.RESISTOR
R36 7030003440 S.RESISTOR
R37 7030003600 S.RESISTOR
R38 7030007520 S.RESISTOR
R39 7030007520 S.RESISTOR
R40 7030003640 S.RESISTOR
R41 7030003640 S.RESISTOR
R42 7030003440 S.RESISTOR
R44 7030003500 S.RESISTOR
R45 7030003500 S.RESISTOR
R46 7030003480 S.RESISTOR
R47 7030003640 S.RESISTOR
R49 7030003440 S.RESISTOR
B: [EUR], [EUR-1], [ESP], [ESP-1], [OTH], [OTH-1]
D: [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1]
F: [FRA], [FRA-1], [ESP], [ESP-1], [OTH], OTH-1], [ITA], [ITA-1]
5 - 1
DESCRIPTION
DA221 TL
DA221 TL
DA221 TL
MA2S111-(TX)
MA2S111-(TX)
DAP222 TL
MA2S111-(TX)
MA2S111-(TX)
DAN222TL
MA2S111-(TX)
DAN222TL
DAP222 TL
DAP222 TL
DAP222 TL
DAN222TL
MA2S111-(TX)
CR-567 (9.8304 MHz)
NL 322522T-101J
HF50ACC 322513-T
HF50ACC 322513-T
HF50ACC 322513-T
HF50ACC 322513-T
ELJFB 102K-F
HF50ACC 453215P-T
HF50ACC 453215P-T
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 151 V (150 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ12YJ2R2U (2.2 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ8ENF 1000V (100 Ω)
ERJ8ENF 1000V (100 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
S.=Surface mount
