Icom IC-703 Service Manual page 35

[PA UNIT]
REF ORDER
NO. NO.
L642 6180003310 COIL
L644 6200005010 S.COIL
L645 6200005010 S.COIL
L750 6110002750 COIL
L751 6110002760 COIL
L752 6110002770 COIL
L753 6110003700 COIL
L754 6110003710 COIL
L755 6110003720 COIL
L756 6110003730 COIL
L757 6150005290 COIL
L758 6150005300 COIL
L761 6200003280 S.COIL
L762 6200003280 S.COIL
L763 6200003280 S.COIL
L764 6200003280 S.COIL
L765 6200003280 S.COIL
L766 6200003280 S.COIL
L767 6200003280 S.COIL
L768 6200003280 S.COIL
L769 6200003280 S.COIL
L770 6200003280 S.COIL
L850 6200003280 S.COIL
L851 6200003280 S.COIL
L852 6200003280 S.COIL
L853 6200003280 S.COIL
L854 6200003280 S.COIL
L855 6200003280 S.COIL
L856 6200003280 S.COIL
L857 6200003280 S.COIL
L858 6200003280 S.COIL
L859 6200003280 S.COIL
L860 6200003280 S.COIL
L890 2040000490 COIL
L900 6200003240 S.COIL
L901 6200003240 S.COIL
L902 6910003570 COIL
L903 6910003570 COIL
R1 7030003200 S.RESISTOR
R2 7030003440 S.RESISTOR
R3 7030003440 S.RESISTOR
R4 7030003440 S.RESISTOR
R5 7030003440 S.RESISTOR
R40 7030003800 S.RESISTOR
R41 7030003440 S.RESISTOR
R42 7030003440 S.RESISTOR
R43 7030003200 S.RESISTOR
R44 7030003440 S.RESISTOR
R45 7030003440 S.RESISTOR
R47 7030003440 S.RESISTOR
R48 7030003440 S.RESISTOR
R49 7030003800 S.RESISTOR
R51 7030003440 S.RESISTOR
R80 7030003680 S.RESISTOR
R81 7030003640 S.RESISTOR
R82 7030003670 S.RESISTOR
R100 7030003570 S.RESISTOR
R101 7030003560 S.RESISTOR
R102 7030003300 S.RESISTOR
R104 7030003490 S.RESISTOR
R107 7030007190 S.RESISTOR
R150 7310002760 S.TRIMMER
R151 7030003540 S.RESISTOR
R152 7030000230 S.RESISTOR
R153 7030003410 S.RESISTOR
R154 7030000140 S.RESISTOR
R155 7030010470 S.RESISTOR
R156 7030000340 S.RESISTOR
R158 7030003460 S.RESISTOR
R159 7310004680 TRIMMER
R160 7030003480 S.RESISTOR
R162 7030003460 S.RESISTOR
R163 7030003480 S.RESISTOR
R164 7310004680 TRIMMER
R201 7030000020 S.RESISTOR
R202 7030000020 S.RESISTOR
A: [EUR], [EUR-1], [USA], [USA-1], [KOR], [KOR-1]
C: [FRA], [FRA-1], [ITA], [ITA-1]
E: [FRA], [FRA-1], [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1]
DESCRIPTION
LR-436
NL 252018T-100J
NL 252018T-100J
LA-459
LA-460
LA-461
LA-567
LA-568
LA-569
LA-570
LR-428
LR-429
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
EXC-ELDR25C
NL 322522T-221J
NL 322522T-221J
2943-666663
2943-666663
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 680 V (68 Ω)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ12YJ220U (22 Ω)
RV-152 (RH03A3AJ4X0HA)
ERJ3GEYJ 682 V (6.8 kΩ)
MCR10EZHJ 56 Ω (560)
ERJ3GEYJ 561 V (560 Ω)
MCR10EZHJ 10 Ω (100)
ERJ1TYJ 5R6U (5.6 Ω)
MCR10EZHJ 470 Ω (471)
ERJ3GEYJ 152 V (1.5 kΩ)
EVM-2AGA00 B14 (103)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
EVM-2AGA00 B14 (103)
MCR10EZHJ 1 Ω (010)
MCR10EZHJ 1 Ω (010)
[PA UNIT]
REF ORDER
NO. NO.
R203 7030000020 S.RESISTOR
R204 7030000020 S.RESISTOR
R205 7030000200 S.RESISTOR
R206 7030000200 S.RESISTOR
R207 7030003500 S.RESISTOR
R208 7030003500 S.RESISTOR
R210 7030010820 S.RESISTOR
R211 7030010820 S.RESISTOR
R213 7030003500 S.RESISTOR
R214 7030003500 S.RESISTOR
R216 7030010810 S.RESISTOR
R250 7030003700 S.RESISTOR
R251 7030003730 S.RESISTOR
R300 7030003510 S.RESISTOR
R301 7030003440 S.RESISTOR
R302 7030003440 S.RESISTOR
R303 7030003550 S.RESISTOR
R304 7030003640 S.RESISTOR
R305 7030003560 S.RESISTOR
R306 7030003200 S.RESISTOR
R400 7030003440 S.RESISTOR
R401 7030003440 S.RESISTOR
R402 7030003640 S.RESISTOR
R403 7030003640 S.RESISTOR
R404 7030003440 S.RESISTOR
R405 7030003440 S.RESISTOR
R406 7030003640 S.RESISTOR
R407 7030003640 S.RESISTOR
R408 7030000210 S.RESISTOR
R409 7030000210 S.RESISTOR
R420 7030003440 S.RESISTOR
R421 7030003440 S.RESISTOR
R422 7030003640 S.RESISTOR
R423 7030003640 S.RESISTOR
R424 7030003440 S.RESISTOR
R425 7030003440 S.RESISTOR
R426 7030003640 S.RESISTOR
R427 7030003640 S.RESISTOR
R428 7030000210 S.RESISTOR
R429 7030000210 S.RESISTOR
R440 7030003440 S.RESISTOR
R441 7030003440 S.RESISTOR
R442 7030003640 S.RESISTOR
R443 7030003640 S.RESISTOR
R444 7030003440 S.RESISTOR
R445 7030003440 S.RESISTOR
R446 7030003640 S.RESISTOR
R447 7030003640 S.RESISTOR
R448 7030000210 S.RESISTOR
R449 7030000210 S.RESISTOR
R460 7030003440 S.RESISTOR
R461 7030003440 S.RESISTOR
R462 7030003640 S.RESISTOR
R463 7030003640 S.RESISTOR
R464 7030003440 S.RESISTOR
R465 7030003440 S.RESISTOR
R466 7030003640 S.RESISTOR
R467 7030003640 S.RESISTOR
R468 7030000210 S.RESISTOR
R469 7030000210 S.RESISTOR
R480 7030003440 S.RESISTOR
R481 7030003440 S.RESISTOR
R482 7030003640 S.RESISTOR
R483 7030003640 S.RESISTOR
R484 7030003440 S.RESISTOR
R485 7030003440 S.RESISTOR
R486 7030003640 S.RESISTOR
R487 7030003640 S.RESISTOR
R488 7030000210 S.RESISTOR
R489 7030000210 S.RESISTOR
R500 7030003440 S.RESISTOR
R501 7030003440 S.RESISTOR
R502 7030003640 S.RESISTOR
R503 7030003640 S.RESISTOR
R504 7030003440 S.RESISTOR
R505 7030003440 S.RESISTOR
R506 7030003640 S.RESISTOR
R507 7030003640 S.RESISTOR
B: [EUR], [EUR-1], [ESP], [ESP-1], [OTH], [OTH-1]
D: [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1]
F: [FRA], [FRA-1], [ESP], [ESP-1], [OTH], OTH-1], [ITA], [ITA-1]
5 - 4
DESCRIPTION
MCR10EZHJ 1 Ω (010)
MCR10EZHJ 1 Ω (010)
MCR10EZHJ 33 Ω (330)
MCR10EZHJ 33 Ω (330)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ1TYJ 221U (220 Ω)
ERJ1TYJ 221U (220 Ω)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERX1HZJ R10H
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 274 V (270 kΩ)
ERJ3GEYJ 392 V (3.9 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
S.=Surface mount
