INTRODUCTION

This service manual describes the latest service information
for the IC-703 HF/50MHz ALL MODE TRANSCEIVER.
MODEL
VERSION
Europe
France
Spain
IC-703 U.S.A.
Korea
Other
Italy
To upgrade quality, any electrical or mechanical parts and
internal circuits are subject to change without notice or
obligation.

ORDERING PARTS

Be sure to include the following four points when ordering
replacement parts:
1. 10-digit order numbers
2. Component part number and name
3. Equipment model name and unit name
4. Quantity required
<SAMPLE ORDER>
1110004080 S.IC PC2709T
8810009610 Screw FH M2.6 6 ZK IC-703
Addresses are provided on the inside back cover for your
convenience.
SYMBOL
UT-106 option UT-106 equipped
EUR EUR-1
FRA-1
FRA
ESP ESP-1
USA USA-1
KOR KOR-1
OTH OTH-1
ITR ITR-1
IC-703 MAIN UNIT
Top cover
NEVER connect the transceiver to an AC outlet or to a DC
power supply that uses more than 16 V. This will ruin the
transceiver.
DO NOT expose the transceiver to rain, snow or any liquids.
DO NOT reverse the polarities of the power supply when con-
necting the transceiver.
DO NOT apply an RF signal of more than 20 dBm (100 mW)
to the antenna connector. This could damage the transceiv-
er's front end.
1. Make sure a problem is internal before disassembling the
transceiver.
2. DO NOT open the transceiver until the transceiver is
disconnected from its power source.
3. DO NOT force any of the variable components. Turn
them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An insu-
lated tuning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the trans-
ceiver is defective.
5 pieces
6. DO NOT transmit power into a signal generator or a
10 pieces
sweep generator.
7. ALWAYS connect a 50 dB to 60 dB attenuator between
the transceiver and a deviation meter or spectrum ana-
lyzer when using such test equipment.
8. READ the instructions of test equipment thoroughly
before connecting equipment to the transceiver.
DANGER

REPAIR NOTES
