Icom IC-703 Service Manual page 45

[MAIN UNIT]
REF ORDER
NO. NO.
R1725 7030003430 S.RESISTOR
R1751 7030003480 S.RESISTOR
R1801 7030003440 S.RESISTOR
R1802 7030003520 S.RESISTOR
R1803 7310004850 S.TRIMMER
R1804 7030003520 S.RESISTOR
R1805 7030003320 S.RESISTOR
R1806 7030003480 S.RESISTOR
R1807 7310002670 S.TRIMMER
R1808 7030003480 S.RESISTOR
R1809 7030003480 S.RESISTOR
R1810 7030003560 S.RESISTOR
R1811 7310002800 S.TRIMMER
R1812 7510001660 S.THRMISTOR NTCG16 4LH 473KT
R1815 7030003440 S.RESISTOR
R1816 7030003640 S.RESISTOR
R1817 7030003680 S.RESISTOR
R1818 7030003400 S.RESISTOR
R1819 7030003420 S.RESISTOR
R1820 7030003320 S.RESISTOR
R1851 7030003540 S.RESISTOR
R1853 7310002720 S.TRIMMER
R1854 7030003440 S.RESISTOR
R1855 7030003720 S.RESISTOR
R1856 7030003440 S.RESISTOR
R1857 7030003640 S.RESISTOR
R1858 7030003440 S.RESISTOR
R1859 7030003640 S.RESISTOR
R1860 7030003440 S.RESISTOR
R1861 7030003640 S.RESISTOR
R1862 7030003540 S.RESISTOR
R1901 7030003320 S.RESISTOR
R1902 7030003320 S.RESISTOR
R1903 7030003610 S.RESISTOR
R2001 7030003440 S.RESISTOR
R2002 7030003680 S.RESISTOR
R2003 7030003650 S.RESISTOR
R2004 7030003280 S.RESISTOR
R2005 7030003440 S.RESISTOR
R2006 7030003640 S.RESISTOR
R2007 7030003560 S.RESISTOR
R2101 7030003700 S.RESISTOR
R2102 7030003580 S.RESISTOR
R2103 7030003740 S.RESISTOR
R2104 7030003500 S.RESISTOR
R2105 7030003440 S.RESISTOR
R2106 7030003640 S.RESISTOR
R2107 7030003500 S.RESISTOR
R2108 7030003640 S.RESISTOR
R2109 7030003440 S.RESISTOR
R2151 7030003560 S.RESISTOR
R2152 7030003630 S.RESISTOR
R2153 7030003700 S.RESISTOR
R2154 7030003700 S.RESISTOR
R2155 7030003560 S.RESISTOR
R2201 7030003580 S.RESISTOR
R2202 7030003590 S.RESISTOR
R2203 7030003680 S.RESISTOR
R2204 7030003680 S.RESISTOR
R2205 7030003680 S.RESISTOR
R2206 7030003720 S.RESISTOR
R2207 7030003440 S.RESISTOR
R2208 7030003440 S.RESISTOR
R2209 7030003440 S.RESISTOR
R2221 7030003680 S.RESISTOR
R2222 7030003680 S.RESISTOR
R2223 7030003700 S.RESISTOR
R2224 7030003680 S.RESISTOR
R2301 7030003560 S.RESISTOR
R2302 7030003560 S.RESISTOR
R2303 7030003580 S.RESISTOR
R2304 7030003640 S.RESISTOR
R2305 7030003760 S.RESISTOR
R2306 7030003610 S.RESISTOR
R2401 7030003560 S.RESISTOR
R2402 7030003560 S.RESISTOR
R2403 7030003640 S.RESISTOR
R2404 7030003680 S.RESISTOR
A: [EUR], [EUR-1], [USA], [USA-1], [KOR], [KOR-1]
C: [FRA], [FRA-1], [ITA], [ITA-1]
E: [FRA], [FRA-1], [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1]
DESCRIPTION
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
EVM-3YSX50 B52 (501)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
RV-143 (RH03A3AS2) 471
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
RV-156 (RH03A3AJ5) 224
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 682 V (6.8 kΩ)
RV-148 (RH03A3AS3X0DA) 472
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 273 V (27 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 334 V (330 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 273 V (27 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
[MAIN UNIT]
REF ORDER
NO. NO.
R2452 7030003440 S.RESISTOR
R2453 7030003440 S.RESISTOR
R2454 7030003440 S.RESISTOR
R2455 7030003440 S.RESISTOR
R2456 7030003440 S.RESISTOR
R2457 7030003440 S.RESISTOR
R2458 7030003560 S.RESISTOR
R2459 7030003440 S.RESISTOR
R2460 7030003560 S.RESISTOR
R2461 7030003440 S.RESISTOR
R2462 7030003440 S.RESISTOR
R2501 7030003600 S.RESISTOR
R2502 7030003440 S.RESISTOR
R2503 7030003760 S.RESISTOR
R2504 7030003320 S.RESISTOR
R2505 7030003320 S.RESISTOR
R2506 7030003440 S.RESISTOR
R2507 7030003560 S.RESISTOR
R2508 7030003580 S.RESISTOR
R2509 7030003660 S.RESISTOR
R2511 7030003440 S.RESISTOR
R2512 7030003640 S.RESISTOR
R2513 7030003440 S.RESISTOR
R2514 7030003640 S.RESISTOR
R2551 7030003840 S.RESISTOR
R2553 7030003750 S.RESISTOR
R2554 7030003680 S.RESISTOR
R2555 7030003440 S.RESISTOR
R2559 7030009920 S.RESISTOR
R2601 7030003580 S.RESISTOR
R2602 7030003590 S.RESISTOR
R2603 7030003640 S.RESISTOR
R2604 7030003680 S.RESISTOR
R2606 7030003370 S.RESISTOR
R2607 7030003700 S.RESISTOR
R2608 7030003700 S.RESISTOR
R2609 7030003720 S.RESISTOR
R2610 7030003730 S.RESISTOR
R2611 7030003700 S.RESISTOR
R2612 7030003750 S.RESISTOR
R2613 7030003670 S.RESISTOR
R2614 7030003670 S.RESISTOR
R2615 7030003450 S.RESISTOR
R2616 7030003440 S.RESISTOR
R2617 7030003560 S.RESISTOR
R2618 7310002590 S.TRIMMER
R2619 7030003410 S.RESISTOR
R2620 7030003600 S.RESISTOR
R2621 7310002720 S.TRIMMER
R2622 7030003610 S.RESISTOR
R2623 7030003440 S.RESISTOR
R2624 7030003640 S.RESISTOR
R2625 7030003500 S.RESISTOR
R2626 7510001660 S.THRMISTOR NTCG16 4LH 473KT
R2651 7030003680 S.RESISTOR
R2652 7030003680 S.RESISTOR
R2702 7030003560 S.RESISTOR
R2704 7030003650 S.RESISTOR
R2705 7310002800 S.TRIMMER
R2706 7310002800 S.TRIMMER
R2707 7310002800 S.TRIMMER
R2708 7030003720 S.RESISTOR
R2709 7030003640 S.RESISTOR
R2710 7030003680 S.RESISTOR
R2711 7030003800 S.RESISTOR
R2712 7030003840 S.RESISTOR
R2713 7030003380 S.RESISTOR
R2714 7030003400 S.RESISTOR
R2721 7030003600 S.RESISTOR
R2722 7030003560 S.RESISTOR
R2723 7030003440 S.RESISTOR
R2724 7030003640 S.RESISTOR
R2725 7030003440 S.RESISTOR
R2726 7030003640 S.RESISTOR
R2727 7030003440 S.RESISTOR
R2728 7030003640 S.RESISTOR
R2729 7030003680 S.RESISTOR
R2741 7030003680 S.RESISTOR
B: [EUR], [EUR-1], [ESP], [ESP-1], [OTH], [OTH-1]
D: [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1]
F: [FRA], [FRA-1], [ESP], [ESP-1], [OTH], OTH-1], [ITA], [ITA-1]
5 - 14
DESCRIPTION
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 225 V (2.2 MΩ)
ERJ3GEYJ 394 V (390 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 335 V (3.3 MΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 274 V (270 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 394 V (390 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
RV-109 (RH03A3AJ3X0BA) 222
ERJ3GEYJ 561 V (560 Ω)
ERJ3GEYJ 223 V (22 kΩ)
RV-148 (RH03A3AS3X0DA) 472
ERJ3GEYJ 273 V (27 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
RV-156 (RH03A3AJ5) 224
RV-156 (RH03A3AJ5) 224
RV-156 (RH03A3AJ5) 224
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 225 V (2.2 MΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
S.=Surface mount
