5. Channel Selector:
Moving to the left gets channel 1-4 output, moving to the right gets channel 5-8
output.
3

Operation Guide

3.1 Channel output and controlling functions

3.1.1 8 channels / 16 channels output control:
8 channels output and 16 channels output are available for the user's application.
•
Switch the CH1-8/CH1-16 selector to "CH1-8" position, then 8-channel output function will
•
be available.
Switch the CH1-8/CH1-16 selector to "CH1-16" position, then 16-channel output function will
•
be available.
3.1.2 EFFECT / LATCH / FLASH function:
Turn on the EFFECT Switch under 8 channels output mode, relevant channel output will run
•
normally.
Turn off the EFFECT Switch under 8 channels output mode, relevant channel output will be
•
disabled.
Press relevant Channel button to lock (LATCH) or trigger (FLASH) the corresponding
•
channel output. Relevant Channel button function (LATCH or FLASH) is controlled by the
FLASH / LATCH selector.
When in 16-CH mode, EFFECT Switch can function as well as in the 8-CH mode. On the
•
other hand, EFFECT Switch can control two relevant channel outputs at the same time.
For example, the EFFECT switch which controls channel 1 can simultaneously control
channel 9 under 16-CH mode. The function of each Channel button will be controlled by the
FLASH / LATCH selector: switch to "LATCH" position for LATCH function, and switch to
"FLASH" position for FLASH function.

3.1.3 Chase speed control:

Relevant Chase speed can be controlled by:
a. the audio signals.
b. SPEED adjuster under
c. SPEED adjuster under 10 min. mode.
Switch the "Chase mode selector" to AUDIO mode, then the Chase speed will go sensitively
•
following the audio signals. Audio sensitivity can also be controlled by the Audio adjuster —
you can get higher levels while adjusting towards "Max", and get lower levels towards "Min".
Switch the "Chase mode selector" to
•
the relative SPEED adjuster, the fastest Chase speed can be within a few seconds.
Switch the "Chase mode selector" to the 10min mode, then the Chase speed will be
•
controlled by the relative SPEED adjuster, the slowest Chase speed can come to the level of
10 minutes.

3.1.4 MANUAL / AUTO Mode

Switch MANUAL/AUTO selector to MANUAL mode, you can then select anyone of the
•
built-in Chasing programs by pressing the Mode button manually. Each tap will change the
program once.
Switch MANUAL/AUTO selector to AUTO mode, then all the 16 built-in Chasing programs
•
will run circularly and automatically.
3.1.5 Enable / disable signal output for Switch Pack
1 mode.
1 mode, then the Chase speed will be controlled by
