CUEPIX PANEL™
user manual



Advertisement

loading

Related Manuals for Elation CUEPIX PANEL

Summary of Contents for Elation CUEPIX PANEL

  • Page 1 CUEPIX PANEL™ user manual    ...
  • Page 2 Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040 323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com Elation Professional B.V.

  • Page 3: Table Of Contents

    . e l a t i o n l i g h t i n g . c o m C O N T E N T S General Information Warranty Safety Instructions General Guidelines Overview Installation Understanding DMX Menu DMX Channel Functions And Values Cleaning and Maintenance Technical Specifications Optional Accessories CUEPIX PANEL™ User Manual Ver. 3...
  • Page 4 G E N E R A L I N F O R M A T I O N INTRODUCTION Congratulations, you have just purchased one of the most innovative and reliable lighting fixtures on the market today! The CUEPIX PANEL ™ has been designed to perform reliably for years when the guidelines in this booklet are followed.
  • Page 5 You may also visit us on the web at www.elationlighting.com any comments or suggestions. For service related issue please contact Elation Professional®. ELATION SERVICE USA - Monday - Friday 8:00am to 5:00pm PST...

  • Page 6: Warranty

    No accessories should be shipped with the product. If any accessories are shipped with the product, Elation Professional® shall have no liability what so ever for loss and/or or damage to any such accessories, nor for the safe return thereof.

  • Page 7: Safety Instructions

    Do not operate this fixture if the power cord has become frayed, crimped and/or damaged. If the power cord is damaged, replace it immediately with a new one of similar power rating. CUEPIX PANEL™ User Manual Ver. 3...

  • Page 8: General Guidelines

    Use the original packaging and materials to transport the fixture in for service. DO NOT TOUCH the housing bare-hand during its operation. Turn OFF the power and allow approximately 15 minutes for the fixture to cool down before replacing or serving. CUEPIX PANEL™ User Manual Ver. 3...

  • Page 9: Overview

    12. DOWN Button Fuse 13. UP Button powerCON IN 14. MODE/ESC Button RJ45 NET OUT 15. Safety Cable Rigging Points powerCON OUT 16. SIDE Coffin Lock 3pin DMX OUT 17. BOTTOM Coffin Lock 5pin DMX OUT CUEPIX PANEL™ User Manual Ver. 3...
  • Page 10 Coffin Lock Latch Rigging Points ( 4 ) P a n e l s M A X p e r e a c h R I G G I N G B A R . CUEPIX PANEL™ User Manual Ver. 3...

  • Page 11: Installation

    The CUEPIX PANEL provides an integrated yoke bracket. When mounting this fixture to truss be sure to secure an appropriately rated clamps to the yoke/rigging bracket using a M10 screw fitted through the center hole. CUEPIX PANEL™ User Manual Ver. 3...
  • Page 12 Improper installation can result in bodily injury. Fixture is fully operational in the specific mounting positions as illustrated below. DO NOT attach panels to panels installed with YOKE. (4) Panels MAX per each RIGGING BAR. CUEPIX PANEL™ User Manual Ver. 3...
  • Page 13 . e l a t i o n l i g h t i n g . c o m SECURING ™ Regardless of the rigging option you choose for your CUEPIX PANEL always be sure to secure your fixture with a safety cable. The fixture provides a built-in rigging point for a safety cable on the base of the unit as illustrated below.
  • Page 14 Always attach independent Safety Cables between truss/structure and each individual panel as illustrated above whenever installing this panel(s) in a suspended environment. NEVER DAISYCHAIN SAFETY CABLES BETWEEN MULTIPLE PANELS CUEPIX PANEL™ User Manual Ver. 3...
  • Page 15 1 to that fixture no matter where it is located in the DMX chain. The CUEPIX PANEL™ can be controlled via DMX-512 protocol and the DMX address is set via the control menu.
  • Page 16 Connect the provided XLR cable to the female XLR output of your controller and the other side to the male XLR input of the CUEPIX PANEL™ The diagram below illustrates a typical DMX-512 connection when the fixture is in the 80 Channel Mode. You can chain multiple panels together through serial linking.
  • Page 17 5pin XLR fixtures may be implemented in a 3pin XLR DMX line. When inserting standard 5pin XLR connectors in to a 3pin line a cable adaptor must be used, these adaptors are readily available at most electric stores. The following chart details a proper cable conversion. CUEPIX PANEL™ User Manual Ver. 3...
  • Page 18 In the case of the CUEPIX PANEL™, when in the 80 Channel Mode you should set the starting DMX address of the first unit to 1, the second unit to 81 (1 + 80), the third unit to 161 (81 + 80), and so on.
  • Page 19 The control panel (see image below) located on the top of the fixture allows you to access the main menu and make all necessary adjustments to the CUEPIX PANEL™. During normal operation, pressing MODE button once will access the fixture’s main menu.
  • Page 20 Fixture ID Set DMX Universe number. 000-255 Universe (Need to enter Service PIN to access this menu) Ethernet Set Kling-Net, ArtNet Set Protocol. Protocol Set Ethernet Set ON, OFF Set Network switch. Network Switch CUEPIX PANEL™ User Manual Ver. 3...
  • Page 21 Speed & Flash Adjustable Seven Color Chase 13.FLOW 8 Speed00-99 Flash00-99 Speed & Flash Adjustable Seven Color Chase 14.FLOW 9 Speed00-99 Flash00-99 Speed & Flash Adjustable Seven Color Chase 15.FLOW 10 Speed00-99 Flash00-99 Speed & Flash Adjustable CUEPIX PANEL™ User Manual Ver. 3...
  • Page 22 PIXEL FLIP Select the desired starting COB module and chase direction from one of the following modes below via UP/DOWN buttons and then press ENTER to confirm. STANDARD FLIP 1 FLIP 2 FLIP 3 CUEPIX PANEL™ User Manual Ver. 3...
  • Page 23 PIXEL FLIP [continued] FLIP 4 DIMMING CURVES The DimCurve menu allows you to select one of the following preset dimming curves: Standard, Stage, TV, Architectural, Theatre, or Default. (See diagram below for more details) Dimmer CUEPIX PANEL™ User Manual Ver. 3...
  • Page 24 *BLUE - COB MODULE 5 0-255 0 to 100% *RED - COB MODULE 6 0-255 0 to 100% *GREEN - COB MODULE 6 0-255 0 to 100% *BLUE - COB MODULE 6 0-255 0 to 100% CUEPIX PANEL™ User Manual Ver. 3...
  • Page 25 *BLUE - COB MODULE 12 0-255 0 to 100% *RED - COB MODULE 13 0-255 0 to 100% *GREEN - COB MODULE 13 0-255 0 to 100% *BLUE - COB MODULE 13 0-255 0 to 100% CUEPIX PANEL™ User Manual Ver. 3...
  • Page 26 *BLUE - COB MODULE 19 0-255 0 to 100% *RED - COB MODULE 20 0-255 0 to 100% *GREEN - COB MODULE 20 0-255 0 to 100% *BLUE - COB MODULE 20 0-255 0 to 100% CUEPIX PANEL™ User Manual Ver. 3...
  • Page 27 *BLUE - COB MODULE 24 0-255 0 to 100% *RED - COB MODULE 25 0-255 0 to 100% *GREEN - COB MODULE 25 0-255 0 to 100% *BLUE - COB MODULE 25 0-255 0 to 100% CUEPIX PANEL™ User Manual Ver. 3...
  • Page 28 FLOW Macro 2 184-191 FLOW Macro 3 192-199 FLOW Macro 4 200-207 FLOW Macro 5 208-215 FLOW Macro 6 216-223 FLOW Macro 7 224-231 FLOW Macro 8 232-239 FLOW Macro 9 240-255 NO FUNCTION CUEPIX PANEL™ User Manual Ver. 3...
  • Page 29 Pulse Effect In Sequence SLOW to FAST 160-191 LEDs ON 192-223 Random Flash / Strobe Effect SLOW to FAST 224-255 LEDs ON DIMMING CURVE MODES 0-20 STANDARD 21-40 STAGE 41-60 61-80 ARCHITECTURAL 81-100 THEATRE 101-255 Default to Unit Setting CUEPIX PANEL™ User Manual Ver. 3...
  • Page 30 Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized Elation service technician. Should you need any spare parts, please order genuine parts from your local Elation dealer.
  • Page 31 Power Linking: 2pcs @120V / 4pcs @220V APPROVALS / RATINGS CE | cETLus | IP20 Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. CUEPIX PANEL™ User Manual Ver. 3...

  • Page 32: Photometric Data

    . e l a t i o n l i g h t i n g . c o m PHOTOMETRIC DATA DIMENSIONAL DRAWINGS Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. CUEPIX PANEL™ User Manual Ver. 3...
  • Page 33 ( H o l d s u p t o 4 P a n e l s M A X ) Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. CUEPIX PANEL™ User Manual Ver. 3...
  • Page 34 O P T I O N A L A C C E S S O R I E S ORDER CODE ITEM CRB001 CUEPIX PANEL Rigging Bracket For (4) Panels MAX CUE295/15LK CUEPIX PANEL 15 Degree Lens Kit CUE211 Software Uploader For CUEPIX Series...
