  • Page 1 LIGHT COPILOT III User Instructions (Rev 1.0 24-004-1264) E-mail: info@ elationlighting.com Internet: http://www.elationlighting.com...

  • Page 2: General Introduction

    1 General Introduction Thank you for your purchase of our product LIGHT COPILOT II. This is a high-performance lighting controller with many useful functions. 8 Channels output and 16 Channels output are available for your application. AUDIO and CHASE control are available by this unit.
  • Page 3 SPEED adjuster upon CH5-8 / CH13-16: To control the Chase speed for 5-8 channels and 13-16 channels. Chase speed adjustment for 13-16 channels can be available under the 16 channels output mode only. User can get higher (lower) speed levels by adjusting the knob towards “Max” ( “Min”). CH1-8 / CH1-16 selector: To select 8 channels output or 16 channels output as the user’s desire.

  • Page 4: Rear Panel

    2.1.2 Rear panel DC INPUT: 9-12VDC,500mA CONTROL OUTPUT 9 - 16 CONTROL OUTPUT 1 - 8 FOG MACHINE AUDIO IN STROBE OUTPUT MADE IN PRC 23-001-2105 CH9-16 outlet: to output signals according to 9-16 channels. CH1-8 outlet: to output signals according to 1-8 channels. Fog machine connector: connects with a fog machine.

  • Page 5: Operation Guide

    Channel Selector: Moving to the left gets channel 1-4 output, moving to the right gets channel 5-8 output. Operation Guide 3.1 Channel output and controlling functions 3.1.1 8 channels / 16 channels output control: 8 channels output and 16 channels output are available for the user’s application. •...

  • Page 6: Specifications

    The signal output for Switch Pack can be controlled by STAND BY button. When the STAND • BY LED blinks, that means the relevant signal output is disabled. Press the STAND BY button again (relevant LED “off”) to reactivate the signal output. 3.2 External strobes control External strobes can be controlled in the following different flash speed modes.
