single, lower tone beep ("BEEEP") followed by a shorter, higher
tone beep ("beep"). If the chimes and beeps do not sound in
this manner refer to "MOTOR/ESC OPERATION" on page
15 to setup the transmitter and ESC correctly.
A magnetic screwdriver, or a small magnet stuck to a screw
driver to make it magnetic, will be helpful for the next couple
of steps.
❏
3. Remove the screw from the connector on the elevator
servo arm.
❏
4. Lightly wet the threads of the screw with threadlocker.
❏
5. Reinstall the screw, but do not tighten yet. With the
transmitter and receiver on, center the elevator and tighten
the screw to lock the pushrod down.
❏
6. Repeat the same procedure for the rudder, making
sure it is centered. Lock the pushrod down with the screw
and threadlocker.
❏
7. Disconnect the battery and turn off the transmitter.

Mount the Wings

❏
1. Fasten the wing clips to both sides of the fuselage with
four M3x10 screws.
