D Group call
When a group call is received;
q
• Beeps sound.
• " " appears and the mute is released.
• The programmed text message (e.g."GROUP") and the calling
station ID (or text) is displayed when the indication mode is 2
lines.
• The programmed text message (e.g."GROUP") and the calling
station ID (or text) is displayed alternately when the indication
mode is 1 line, depending on the setting.
• " " appears or blinks depending on the setting.
Appears
G R O U P
Push and hold [PTT], then speak into the microphone at a
w
normal voice level.
• TX indicator lights red.
NOTE: Only one station is permitted to speak.
Release [PTT] to return to receive.
e
• BUSY indicator lights green while receiving a signal.
To finish the conversation, push [P4] (Moni(Audi)) to send
r
the 'Clear down' signal.
• Either station can send a 'Clear down' signal.
• "CLR DOWN" is displayed for 2 sec. (approx.)
• " " disappears and the transceiver returns to the standby con-
dition.
Appears or blinks
1 1 2 0
D Displaying the received call record
— Queue indication
The transceiver memorizes the calling station ID in the mem-
ory. Up to 3 calls can be memorized, and the oldest call re-
cord is erased when a 4th call is received. However, once the
transceiver is powered OFF, the all records are cleared.
Push [P1] (Digital) for 1 sec.
q
• Displays following indication.
When a record is available
< Q U E U E >
- Q U E U E ! -
When no record is available
< Q U E U E >
N O Q U E U E
Push [Up] or [Down], or rotate [DIAL] to select the desired
w
call.
Push [P1] (Digital) for 1 sec. again to return to the standby
e
condition.
• When no operation is performed for 30 sec., the transceiver re-
turns to the standby condition automatically.
3
