- Page 1 INSTRUCTION MANUAL VHF TRANSCEIVER iF15/S UHF TRANSCEIVER iF25/S...
- Page 2 Exposing the inside of the transceiver to water will result in serious damage to the transceiver. The use of non-Icom battery packs/chargers may impair transceiver OPERATING NOTES performance and invalidate the warranty.
- Page 3 ACCESSORIES ■ Supplied accessories TABLE OF CONTENTS The following accessories are supplied: Qty. FOREWORD ……………………………………………………………… i q Flexible antenna ........1 EXPLICIT DEFINITIONS …………………………………………………...
- Page 4 ACCESSORIES ACCESSORIES ■ Accessory attachments D Flexible antenna ï Battery pack Connect the supplied flexible an- To attach the battery pack: tenna to the antenna connector. Slide the battery pack on the back of the transceiver in the direc- tion of the arrow (q), then lock it with the battery release button. CAUTION: •...
- Page 5 ACCESSORIES ACCESSORIES D Belt clip ï Jack cover Attach the jack cover when the optional speaker-microphone is not To attach the belt clip: q Release the battery pack if it is attached. used. w Slide the belt clip in the direction of the arrow until the belt clip is To attach the jack cover: To detach the jack cover: q Attach the jack cover to the...
- Page 6 PANEL DESCRIPTION PANEL DESCRIPTION ■ Front, top and side panels e LED INDICATOR (p. 8) IC-F15S/F25S IC-F15/F25 ➥ Lights red while transmitting. ➥ Lights green while receiving a signal, or when the squelch is open. ➥ Lights/blinks orange when the matched 2/5-tone code is re- ceived, according to the pre-programming.
- Page 7 (Ref.; R=Red, G=Green, O=Orange) Consult your Icom dealer or system operator for details concerning your transceivers programming. If the programmable function names are bracketed in the following explanations, the specific key used to activate the function depends on programming.
- Page 8 PANEL DESCRIPTION PANEL DESCRIPTION MONITOR KEY DTMF AUTODIAL KEY ➥ Mute and release the CTCSS (DTCS) or 2-tone squelch mute. Push to transmit the programmed DTMF code. Open any squelch/deactivate any mute while pushing this key. CALL KEYS (LMR operation only) Push to transmit a 2/5-tone code.
- Page 9 CONVENTIONAL OPERATION CONVENTIONAL OPERATION ■ Turning power ON ■ Call procedure ➥ Rotate [VOL] to turn power ON. When your system employs tone signalling (excluding CTCSS and DTCS), the call procedure may be necessary prior to voice trans- [VOL] mission. The tone signalling employed may be a selective calling system which allows you to call specific station(s) only and prevent unwanted stations from contacting you.
- Page 10 CONVENTIONAL OPERATION CONVENTIONAL OPERATION ■ Receiving and transmitting D Transmitting notes NOTE: Transmitting without an antenna may damage the trans- ceiver. See p. 2 for antenna attachment. • Transmit inhibit function The transceiver has several inhibit functions which restrict trans- Receiving: mission under the following conditions: q Rotate [VOL] to turn power ON.
