Nady Systems MGT-16 Owner's Manual

16-channel mini uhf wireless instrument system
Hide thumbs Also See for MGT-16:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
O w n e r ' s M a n u a l
MGT-16
16-Channel Mini uHF
wireless Instrument system

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MGT-16 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nady Systems MGT-16

Summary of Contents for Nady Systems MGT-16

  • Page 1 O w n e r ’ s M a n u a l MGT-16 16-Channel Mini uHF wireless Instrument system...

  • Page 2: Table Of Contents

    Warranty ..........................15 Introduction Thank you for choosing the Nady MGT-16 wireless system, we know you will be very pleased with its performance and features. The Nady MGT-16 is a 16-channel ultra compact UHF wireless system designed for guitar and bass. The MGT-16 has 16 selectable frequencies, up to 250’...

  • Page 3: System Features

    System Features MGT-16 system Features MT-16a & MT-16r Transmitters • UHF wireless system for guitar/bass • Choice of two transmitter housings— MT-16A with 30° angled ¼” plug for use • 16 user-selectable PLL frequencies with either recessed or surface mounted for interference-free operation jacks, or MT-16R with 90°...

  • Page 4: Quick User Controls Guide

    Quick User Controls Guide MGT-16 Instrument receiver IR PO LO RX OFF ON POWER LEVEL 1 2 3 4 CHANNEL...
  • Page 5 CHANNEL SELECT DIP-SWITCH Select one of 14. ASC IR SYNC BUTTON Press to make the IR link ™ 16 pre-set channels per MGT-16 DIP-Switch download the receiver’s selected frequency to Frequency Selection Chart (see page 14) the TX. First, turn on the MT-16A/R transmitter...
  • Page 6 Quick User Controls Guide MT-16a/r Instrument Transmitter MT-16R (Straight plug) MT-16A (Angled plug) 17. POWER SWITCH To power transmitter Off/On 23. INTERNAL AUDIO LEVEL ADJUST Remove battery to access slot and adjust internal trim-pot 18. 15dB ATTENUATION PAD Select to reduce the with small screwdriver for optimal input input gain by 15dB for higher level audio level setting.

  • Page 7: System Operation

    Power adaptor (16). Plug the adapter’s barrel plug into the DC Input Jack (8) The MGT-16 receiver can operate with either on the back of the receiver, then plug the two AA size batteries (DC operation) or with adapter into an AC outlet.

  • Page 8: Adjusting The Squelch

    Finding Open Channels on page 12. adjusting the squelch The Ir sync Button (14) on the MGT-16 receiver is used to transfer the selected frequency The rF squelch (13) control should be info from the receiver to the transmitter for adjusted counterclockwise to the minimum quick synchronization prior to use.

  • Page 9: Mt-16A/R Instrument Transmitter

    Connecting audio Output As the batteries weaken, the Low Battery The MGT-16 receiver’s audio Output Jack Indicator will flash to warn that the battery (7) is a ¼” unbalanced line out and its level level is too low and should be replaced as is controlled by the Volume Knob (3).
  • Page 10 Ir sync window (1) receiver volume and transmitter input pad on the receiver (see Selecting the MGT-16 settings are best for your application. To Receiver Channel and IR Sync on page 8).

  • Page 11: Specifications

    Specifications MGT-16 sysTeM Frequency response 50Hz–16kHz (-3dB) Dynamic range 120dB Oscillating system Phase Lock Loop (PLL) Total Harmonic Distortion (THD) <0.8% rF Carrier Frequency range 902.40MHz–923.70MHz Modulation FM (F3E), +/-30KHz normal Operating range Up to 250 feet (typical, depending on site conditions)

  • Page 12: Cautions And Troubleshooting

    RF channel. Make sure that the receiver Power switch (2) on the MGT-16 receiver is not in the second position (audio muted/attenuated). The receiver’s unbalanced audio Out (7) is adjustable, so make sure the Volume Control (3) is set properly.

  • Page 13: Miscellaneous Tips

    Miscellaneous Tips • The receiver antennas should be kept Keep antennas away from noise sources away from any metal surfaces whenever such as motors, automobiles, neon light, possible as they can reflect away or shield signal processors, computers, and large the incoming RF signal.

  • Page 14: Mgt-16 Dip-Switch Frequency Selection Chart

    Include a brief description of the problem you are experiencing. For service of a unit under warranty, please follow the instructions in the following section. Outside the u.s. For service or warranty matters please contact the Nady distributor in your country through the dealer/store from which you purchased this product.

  • Page 15: Warranty

    2) Send the unit back to Nady Systems, 6701 Shellmound Street, Emeryville, CA, 94608, freight pre-paid. You must include proof of date and place of purchase (i.e., photocopy of your bill of sale) or Nady cannot be responsible for repair or replacement. Nady Systems, Inc. will not repair, nor be held responsible, for any units returned without proper identification, return address, and R/A number clearly marked on the package.
  • Page 16 6701 Shellmound Street | Emeryville, CA USA 94608 T 510.652.2411 | F 510.652.5075 | www.nady.com...
