Nady Systems UHF-7 Owner's Manual

Single channel uhf digitru diversity wireless system

Advertisement

Quick Links

SERVICE
(U.S.) Should your Nady Wireless Microphone System require service, please contact
the Nady Service Department via telephone at (510) 652-2411 or e-mail to
service@nady.com for a Return Authorization (R/A) Number and a service quote (if
out of warranty). Make sure the R/A Number is clearly marked on the outside of the
package and enclose a cashier's check or money order (if not prepaid with a credit
card). Ship the unit prepaid to: Nady Systems, Inc., Service Department, 6701
Shellmound Street, Emeryville, CA 94608. Include a brief description of the problems
you are experiencing.
The warranty card enclosed with this system contains additional valuable
warranty and service information. Keep it in a safe place for future possible
reference. Do not attempt to service this unit yourself as it will void the warranty.
(International) For service, please contact the Nady distributor in your country
through the dealer from whom you purchased this product.
Nady Wireless Systems are type accepted under FCC rules parts 90, 74 and 15. The
device complies with RSS-210 of Industry & Science Canada. Operation is subject to
the following two conditions: (1) this device may not cause harmful interference and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
NADY SYSTEMS, INC.
6701 Shellmound Street • Emeryville, CA 94608 USA
Tel: 510/652-2411 • Fax: 510/652-5075
www.nady.com
UHF-7
Single Channel UHF DigiTRU Diversity™
Wireless System
OWNER'S MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the UHF-7 and is the answer not in the manual?

Questions and answers

Summary of Contents for Nady Systems UHF-7

  • Page 1 Wireless System Nady Wireless Systems are type accepted under FCC rules parts 90, 74 and 15. The device complies with RSS-210 of Industry & Science Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 2 UH: 9V Alkaline UB: 9V Alkaline Battery Life 10 Hours This manual will first list the features of the UHF-7 and then will take you step by step Dimensions UB Bodypack: 4.25” x 2.5”x 1.0” to show you how to operate your new system. After reading the receiver instructions, (10.8 cm x 6.4 cm x 2.5 cm)
  • Page 3 Dynamic Range, and the clearest, most natural sound available G H L • Tone Squelch™ for locking out potential interference • UHF-7 receiver with DigiTRU Diversity™ for maximum range and dropout protection, full LED indicators, both 1/4" unbalanced and XLR balanced outputs, and special circuitry for noiseless transmitter ON/OFF switching •...
  • Page 4 Plug the 1/4” phone plug into the instrument. When ready to play, slide the audio There are 2 options available for rackmounting the UHF-7 receiver: singly or side-by- MUTE SWITCH (26) to “ON” position Adjust the volume of the receiver as per the side with another UHF-7 Series receiver.
  • Page 5 . The AF LEVEL LED DISPLAY (13) on the UHF-7 receiver will light up to 5 LEDs (4 green and 1 red) for all input signals. Occasional flickering on and off during use of...
  • Page 6 3. The microphone is now ready to use. The A or B DIVERSITY LED INDICATORS (13) on the UHF-7 receiver should now be lit, indicating a received signal from the transmitter. When ready to speak, slide the OFF/STANDBY/ON SWITCH (19) to the ON position.
