3
Installing the Hardware
Refer to your computer's documentation for instructions on opening
and closing the computer, identifying PCI expansion slots, disabling on-
board graphics acceleration, and adding an expansion board.
Start the Installation
To start the installation:
1.
Turn off power to the computer and to the monitor.
2.
Open the computer to gain access to the PCI expansion slots.
3.
If your computer has an installed graphics accelerator, remove it.
If your computer has a graphics accelerator integrated onto the
system board, disable it.
4.
Select the PCI expansion slot into which you will install the Intense
3D 100 board.
NOTE
The selected slot must support PCI bus mastering. In most
computers, all PCI slots have this ability.
5.
Remove the slot cover from the selected PCI slot. Retain the
screws from the slot cover; you will use them to secure the Intense
3D 100 board to the computer's chassis.
Install the Board
To install an Intense 3D 100 board:
1.
Align the board with the PCI expansion slot, ensuring that the gold-
fingered connectors on the board's edge are aligned properly with
the slot connector.
2.
Push the board into the slot firmly and evenly until it is fully seated
in the slot connector.
3.
Visually inspect the connection. If it does not appear to be correct,
remove and reinstall the board.
4.
Use the screws you removed previously to secure the board to the
computer's chassis.
7
