Vga Video Display Support - Intergraph Intense 3D Pro 3400 Installation Manual

20
Intense 3D Pro 3400 supports Intergraph InterView-20, InterView-21,
and InterView-27 monitors at the following resolutions and maximum
refresh rates (Hz). Note that i indicates an interlaced frequency.
Resolution
640 x 480
800 x 600
1024 x 768
1280 x 960
1280 x 1024
Intense 3D Pro 3400 supports InterView 28hd96 monitors at the
following resolutions and maximum refresh rates (Hz). Note that i
indicates an interlaced frequency.
Resolution
640 x 480
800 x 600
1024 x 768
856 x 480
1280 x 720
1360 x 766
1520 x 856
Intense 3D Pro 3400 supports Sony GDM-W900 monitors at the
following resolutions and maximum refresh rates (Hz).
Resolution
640 x 480
1280 x 1024
1280 x 800
1440 x 900

VGA Video Display Support

The Intense 3D Pro 3400 Graphics Accelerator provides onboard VGA
video display support. The maximum resolution supported is 800 x
600, 4 bits per pixel, at 60 Hz vertical refresh.
Aspect Bits Per
Ratio Pixel
4 x 3 128
4 x 3 128
4 x 3 128
4 x 3 100
5 x 4 100
Aspect Bits Per
Ratio Pixel
4 x 3 128
4 x 3 128
4 x 3 128
16 x 9 128
16 x 9 128
16 x 9 100
16 x 9 100
Aspect Bits Per
Ratio Pixel
4 x 3 128
5 x 4 100
16 x 10 128
16 x 10 100
Vertical Refresh Rates (Hz)
154 (20), 185 (21), 151 (27)
126 (20), 153 (21), 123 (27)
99 (20), 122 (21), 98 (27)
81 (20), 79 (27)
76 (20), 72i (20), 74 (27), 70i (27)
Vertical Refresh Rates (Hz)
75
75
75
50, 60, 75
50, 60, 75
72, 75, 85, 90, 60i
60, 70, 75, 85, 60i
Vertical Refresh Rates (Hz)
60
75
60, 75, 85, 90
60, 75, 85
