- Page 1 HDMI to DVI + SPDIF(Coaxial) Converter Operation Manual CP-267S...
- Page 3 TABLE OF CONTENTS 1. Introduction................. 1 2. Features..................1 3. Package Contents..............1 4. Operation Controls and Functions..........1 4.1 Front Panel................1 4.2 Rear Panel................1 5. Connection and Installation............2 6. Pin Configuration................ 2 7. DVI-D Output Pin Assignment............ 3 8.
-
Page 4: Package Contents
1. Introduction This converter box is designed to convert video and audio signal from HDMI source to DVI plus Coaxial audio outputs. The product allows you to connect the HDMI source to a display with DVI input meanwhile extract digital audio signal from the same source to an audio receiver. The HDMI converter box also does signal amplification and equalization for incoming TMDS data before re-transmitting them with optimal quality regardless of the incoming signal quality. -
Page 5: Connection And Installation
3 DVI Output: Connect the DVI output port to the input port of your DVI display such as monitor or projector. Or, connect to the HDMI output port of your LCD TV, using DVI to HDMI cable or adapter. Note that this jack is of DVI-I type, but only DVI-D (digital video) signal will be supported. -
Page 6: Specifications
7. DVI-D Output Pin Assignment DVI-Digital(DVI-D): Supports digital-only connections between the host computer and display. This interface is designed for a 12 or 24-pin connection to enable single or dual-link mode activation. 8 C1 C2 Digital only connector pin assignments Signal Assignment Signal Assignment Signal Assignment... - Page 7 2008.1.16 MPM-CP267S...
- Page 8 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw...
