Summary of Contents for CYP CP-268S

  • Page 1 CP-268S DVI/Coaxial to HDMI Converter Operation Manual CP-268S...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Introduction................1 2. Features..................1 3. Package Contents..............1 4. Operation Controls and Functions.......... 2 4.1 Front Panel..............2 4.2 Rear Panel..............2 5. Pin Configuration............... 3 6. HDMI Output Pin Assignment ..........3 6.1 General Specifications..........3 6.2 Supports Resolution............3 7.
  • Page 3: Introduction

    1. Introduction This HDMI converter box converts DVI/Coaxial signals into HDMI output. It enables us to connect DVI and digital audio sources to an HDMI display. This device also amplifies and equalizes incoming TMDS data before re-transmitting it in optimal quality regardless of its original signal quality. 2.
  • Page 4: Operation Controls And Functions

    4. Operation Controls and Functions 4.1. Front Panel ① DVI input: Connect the DVI input port to the DVI output port of your source device such as a DVD/ Blu Ray player or set-top-box. This Converter only supports a DVI-D signal via a DVI-I connector. ②...
  • Page 5: Pin Configuration

    5. Pin Configuration A. DVI-D Input Pin Assignment DVI-Digital(DVI-D): Supports digital-only connections between the host computer and display. This interface is designed for a 12 or 24-pin connection to enable single or dual-link mode activation. 8 C1 C2 Digital only connector pin assignments Signal Assignment Signal Assignment Signal Assignment...
  • Page 6: Specifications

    7. Specifications Input ports 1 x DVI (only DVI-D supported) , 1 x Coaxial (S/PDIF) Output port 1 x HDMI Power Supply 5V/1A DC (US/EU standards, CE/FCC/UL certified) Dimensions (mm) 105(W) x 76(D) x 30(H) Weight(g) Chassis Material Aluminum Silkscreen Color Silver Operating Temperature 0°C ~ 40°C...
  • Page 8 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20080324 MPM-CP268S...
