CyberData 4-Port PoweredUSB 2.0 Hub Operation Manual page 17

4-port poweredusb 2.0 hub with external power supply and dell integrator kit

Hide thumbs Also See for 4-Port PoweredUSB 2.0 Hub:

Table of Contents

Chapter 1 Installing and using the Hub

Connections

Figure 13: "Y" Cable, +24V PoweredUSB to 3-Pin Power Mini-DIN and USB "B" Connectors

Figure 14: RS232 to USB Converter "Y" Cable +12V (PC Enumerates this device as an RS-232

COM port)

Figure 15: Cable, +24V PoweredUSB to 1x8 PoweredUSB

4-Port PoweredUSB 2.0 Hub with Dell Retail Integrator Kit 010776A

CyberData Corporation Rev C 2/06
