Peripheral cable connection options
Figures 10 through 16 provide examples of peripheral cable combinations and connection options
for the CyberData 4-Port PoweredUSB 2.0 Hub. The following table provides details about the
CyberData PoweredUSB Cables displayed in these figures.
PoweredUSB
Custom cables of different lengths and colors can be purchased from CyberData as follows:
cable sources
●
●
Figure
"Figure 10"on page 15
"Figure 11"on page 16
"Figure 12"on page 16
"Figure 13"on page 17
"Figure 14"on page 17
"Figure 15"on page 17
"Figure 16"on page 18
Figure 10: Cable, +12V PoweredUSB to 2x4 PoweredUSB
4-Port PoweredUSB 2.0 Hub with Dell Retail Integrator Kit 010776A
Via email: sales@cyberdata.net
Via phone: Sales (831) 373-2601 Extension 334
CyberData PoweredUSB Cables
PoweredUSB Cable Description
12V to 2x4
12V to 12V Power Jack
24V PoweredUSB to 3-Pin Power Mini-DIN
24V to "Y" Cable 3-Pin Power Mini-DIN to USB "B"
12V to "Y" Cable, RS232 and Power Jack
24V to 1x8
24V to "Y" Cable, RS232 and Power Jack
Chapter 1 Installing and using the Hub
Connections
CyberData Part Number
010693C
Contact CyberData
010631A
010714A
010763
010617A
CyberData Corporation Rev C 2/06
15
