- Page 1 Grandstream Networks, Inc. Analog IP Gateway GXW410x 4 or 8 FXO Ports w/Video Surveillance GXW410x User Manual Firmware Version 1.3.1.6 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
-
Page 2: Table Of Contents
TABLE OF CONTENTS GXW410X USER MANUAL WELCOME ..............................5 Gateway GXW410x Overview..........................5 Safety Compliances..............................5 Warranty.................................5 PACKAGING ..............................6 GXW410 ............................6 ONNECTING APPLICATION DESCRIPTION........................8 Functional Diagram of IPPBX & GXW410x......................8 GXW400x & GXW410x Scenario/Toll Free Calling Between Locations.............9 FXS and FXO Gateway Configuration Example....................10 FEATURES...............................10 F O .............................10 OFTWARE EATURES VERVIEW S .............................11 ARDWARE PECIFICATION CONFIGURATION GUIDE........................13 W B ..........................13 ONFIGURATION WITH ROWSER Accessing the Web Configuration Menu.......................13 Enduser Configuration............................13 U S ............................17 DVANCED ETTINGS Advanced User Configuration ..........................17... - Page 3 TABLE OF FIGURES GXW410X USER MANUAL FIGURE 1: DIAGRAM OF GXW410X BACK PANEL................6 FIGURE 2: DIAGRAM OF GXW410X DISPLAY PANEL................7 FIGURE 7: SCREENSHOT OF VIDEO SURVEILLANCE* ..............30 APPLICATION ONE: GXW CONNECTED WITH AN IPPBX OR SIP SERVER........34 APPLICATION TWO: GXW TO EXTEND A TRADITIONAL PBX SCENARIO........34 APPLICATION THREE: GXW CONNECTED WITH AN IPPBX OR SIP SERVER AND VIDEO SURVEILLANCE............................35 APPLICATION FOUR: USING A GXW FOR PURE IP IP COMMUNICATION CONFIGURATION..36 INDEX OF TABLES GXW410X USER MANUAL TABLE 1: DEFINITIONS OF THE GXW CONNECTORS................6 TABLE 2: DEFINITIONS OF THE GXW DISPLAY PANEL...............7 TABLE 4: HARDWARE SPECIFICATION OF GXW410X ..............11 TABLE 3: GXW410X SOFTWARE FEATURES..................12 TABLE 6: WEB LOGIN DEFINITIONS (BASIC SETTINGS PAGE)............14 TABLE 7: STATUS PAGE DEFINITIONS....................15 TABLE 8: ADVANCED CONFIGURATION PAGE DEFINITIONS............17 TABLE 9: FXO LINES CONFIGURATION DEFINITIONS...............20 TABLE 10: FXO LINE TEST TAB DEFINITIONS..................23 TABLE 11: CHANNELS PAGE DEFINITIONS..................24 TABLE 12: CHANNELS PAGE DEFINITIONS..................26 TABLE 13: PROFILE PAGE DEFINITIONS....................26 GXW410x User Manual Firmware Version 1.3.1.6 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
-
Page 4: Gxw410X User Manual
GUI INTERFACES GXW410X USER MANUAL http://www.grandstream.com/support/gxw_series/gxw410x/documents/gxw410x_gui.zip 1. S A S C P CREENSHOT DVANCED ETTINGS ONFIGURATION 2. S B S C P CREENSHOT ASIC ETTINGS ONFIGURATION 3. S C C P CREENSHOT HANNELS ONFIGURATION 4. S FXO L C P... -
Page 5: Welcome
C AFETY OMPLIANCES The GXW410x is compliant with various safety standards including FCC/CE. Its power adapter is compliant with UL standard. Warning: use only the power adapter included in the GXW410x package. Using an alternative power adapter may permanently damage the unit. ARRANTY Grandstream has a reseller agreement with our reseller customer. Endusers should contact the ... -
Page 6: Packaging
Reproduction or transmittal of the entire or any part, in any form or by any means, electronic or print, for any purpose without the express written permission of Grandstream Networks, Inc. is not permitted. PACKAGING Unpack and check all accessories. Equipment included in the package: 1) One GXW410x Unit 2) One universal power adapter 3) One Ethernet cable GXW410 ONNECTING 1: D GXW410 B P IGURE IAGRAM ANEL 1: D GXW C ABLE EFINITIONS ONNECTORS LAN (or PC) Connect your PC to this port. It will then be assigned an IP address from your ... -
Page 7: Figure 2: Diagram Of Gxw410 X Display Panel
2: D GXW410 D P IGURE IAGRAM ISPLAY ANEL 2: D GXW D P ABLE EFINITIONS ISPLAY ANEL Power LED Indicates Power. Remains ON when Power is connected and unit is turned ON. Ready LED Remains ON after bootup. LAN LED Indicates LAN (or WAN) port activity PC LED Indicates PC (or LAN) port activity Video LED Remains solid green on bootup. If Video IN terminal is connected, indicates video activity. LEDs 1 8 Indicate status of the respective FXO Ports on the back panel Busy ON Available OFF NOTE: All LEDs display green when ON. The Ready light will only be ON when the network interface is ready and the Web User Interface is accessible. During a firmware upgrade or configuration download the following LED pattern will be observed: Power, Ready, Video and WAN LEDs will be ON. The FXO port LED will keep flashing during download and then stay OFF while the new files are written. The entire process may take between 20 to 30 minutes. The firmware upgrade is complete when you can login into the web configuration pages. ... -
Page 8: Application Description
Phones PSTN Analog endpoints For incoming calls from the PSTN analog endpoints to the GXW410x gateway, the device will auto forward each call to a configured IP extension. The SIP Server can then route the call based on its own configuration or IVR system. VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 9: Gxw400X & Gxw410X Scenario/Toll Free Calling Between Locations
PSTN endpoints connected to the GXW410x gateway will be routed automatically to the analog endpoints connected to the GXW400x gateway. VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 10: Fxs And Fxo Gateway Configuration Example
FXS FXO G C E ATEWAY ONFIGURATION XAMPLE GXW400 G GXW410 G ATEWAY ATEWAY Profile 1 Advanced Settings STUN Server Blank SIP Server Set it to IP Address of Use Random Port No GXW410x SIP Registration No Outgoing Call without Registration Yes NAT traversal – No Advanced Settings FXO lines STUN Server Blank Wait for Dial Tone Y or N (whichever works for your PSTN Service Provider) Stage Method 1 Unconditional Call Forward to VOIP: ch18:444; @ch18:p1; ch18:5060++; Channels 18 5060 Profile 1 Local SIP Listen port (For VOIP to PSTN calls) 5060++ Profile 1 SIP Server Set it to IP Address of GXW400x SIP Registration No NAT traversal No For more information regarding this setup, email Grandstream technical support at support@grandstream.com or visit our User and Developer forum at forums.grandstream.com VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 11: Features
EATURES The GXW410x is a next generation IP voice and video gateway that features full interoperability with leading IPPBXs, Softswitches and SIP platforms. The GXW410x series gateways offer superb voice and video quality, traditional telephony functionality, simple configuration, featurerich functionality and an additional video port that enables the gateway to act as a video surveillance gateway. F O OFTWARE EATURES VERVIEW 4 and 8 FXO port media gateways Video surveillance port External power supply Two RJ45 ports (switched or routed) TFTP and HTTP firmware upgrade support Multiple SIP accounts, multiple SIP profiles (choice of 3 profiles per account) Supports Audio Codecs: G711U/A, G723, G729A/B and GSM Supports Video Codecs: H.264 G.168 – echo cancellation Flexible DTMF transmission: In Audio, RFC2833, SIP Info or any combination of the 3 ... -
Page 12: Table 3: Gxw410X Software Features
3: GXW410 S F ABLE OFTWARE EATURES GXW410x FX0 Analog Gateway Series IP settings GXW4104: 4 ports; 4 SIP accounts w/ choice of 3 SIP Server profiles GXW4108: 8 ports; 8 SIP accounts w/ choice of 3 SIP Server profiles Roundrobin port scheduling to ensure available lines to access PSTN networks Telephone Interface FXO, RJ11 Network Interface Two (2) 10/100 Mbps, RJ45 LED Indicators Power, Video, and Line LEDs On/Off Switch Voice over Packet G.168 compliant Echo Cancellation, Dynamic Jitter Buffer, Capabilities Modem detection & autoswitch to G.711 Voice Compression G.711U, G711A, G.723, G.729A/B, GSM Video Surveillance Realtime H.264 base CIF resolution DHCP Server/Client Switch Mode and PPPoE Fax over IP T.38 compliant Group 3 Fax Relay up to 14.4kpbs and autoswitch to G.711 for Fax Passthrough Diffserve, TOS, 802.1 P/Q VLAN tagging IP Transport RTP/RTCP and RTSP PSTN Signaling FXO Loop start, Current Disconnect. DTMF Method Flexible DTMF transmission method, User interface of Inaudio, RFC2833, and SIP Info IP Signaling SIP (RFC 3261) -
Page 13: Configuration Guide
G ONFIGURATION UIDE W B ONFIGURATION WITH ROWSER The GXW410x gateways have an embedded Web server that will allow a user to configure the IP phone through any web browser. Examples of GUI interfaces can be downloaded @ http://www.grandstream.com/support/gxw_series/gxw410x/documents/gxw410x_gui.zip W C M CCESSING ONFIGURATION Navigate your browser to: http://www.grandstream.com/DOWNLOAD/IPQuery/IPQuery.zip 2. Run the Grandstream IPQuery tool, that you just downloaded. 3. Click on button in order to begin device detection 4. The detected devices will appear in the Output field C USER ONFIGURATION When the Web Configuration Menu is accessed, the GXW410x will respond with a login screen. There are two default passwords for the login page: User Level: Password: Web pages allowed: Enduser Level Only Status and Basic Settings Administrator Level admin All pages can be browsed. -
Page 14: Table 6: Web Login Definitions (Basic Settings Page)
ASIC ETTINGS Web Access Select HTTP or secure HTTPS protocol for Web Access Web Port By default, HTTP uses port 80 and HTTPS uses port 443. This field is for customizable web port. Enduser Password This contains the password to access the Enduser Web Configuration Menu (Status and Basic Settings). This field is case sensitive with a maximum length of 25 characters. IP Address There are two modes to operate the GXW410x: DHCP mode: all the field values for the Static IP mode are not used (even though they are still saved in the Flash memory.) The GXW410x acquires its IP address from the first DHCP server it discovers from the LAN it is connected. Using the PPPoE feature: set the PPPoE account settings. The GXW410x will establish a PPPoE session if any of the PPPoE fields is set. Static IP mode: configure the IP address, Subnet Mask, Default Router IP address, DNS Server 1 (primary), DNS Server 2 (secondary) fields. DHCP hostname This option specifies the name of the client. This field is optional but may be required by some Internet Service Providers. Default is blank. DHCP domain This option specifies the domain name that client should use when resolving hostnames via the Domain Name System. Default is blank. DHCP vendor class ID Used ... -
Page 15: Table 7: Status Page Definitions
Examples: US where daylight saving time is applicable: 03,11,0,02,00;11,4,0,02,00;60 This means the daylight saving time starts from 11 March at 2AM and ends November 4th at 2AM. The saving is 60 minutes (1hour). You may also access the Device Status page which provides details of the GXW product. The Device Status page terms are defined in Table 7: Status Page Definitions. 7: S P D ABLE TATUS EFINITIONS Hardware Revision Hardware version number: Main Board, Interface Board MAC Address The device ID in HEX format. This is a very important ID for ISP troubleshooting. IP Address This field shows WAN IP address of GXW410x Product Model This field contains the product model info (GXW4104 or GXW4108) Software Version Program: This is the main software release. Boot and Loader are not changed often. System Up Time This field shows system up time since the last reboot. Registered This field indicates whether the different SIP Accounts configured under Channels page are successfully registered to the SIP server(s). VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... - Page 16 Additionally it will also provide real time Caller ID information of Incoming as well as Outgoing calls. PPPoE Link Up This field shows whether the PPPoE connection is running if connected to DSL modem. Detected NAT Type This field shows what kind NAT the GXW410x is connected to via its WAN port. It is based on STUN protocol. VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
-
Page 17: Advanced User Settings
G723 voice frame contains 30ms of audio. Similarly, if this field is set to be 2 and if the first vocoder chosen is G729 or G711 or G726, then the “ptime” value in the SDP message of an INVITE request will be 20ms. If the configured voice frames per TX exceeds the maximum allowed value, the gateway will use and save the maximum allowed value for the corresponding first vocoder choice. The maximum value for PCM is 10(x10ms) frames; for G726, it is 20 (x10ms) frames; for G723, it is 32 (x30ms) frames; for G729/G728, 64 (x10ms) and 64 (x2.5ms) frames respectively. Layer 3 QoS This field defines the layer 3 QoS parameter which can be the value used for IP Precedence or DiffServ or MPLS. Default value is 48. Its range lies from 0 to 63. Layer 2 QoS This contains the value used for layer 2 VLAN tag. 802.1q / VLAN tag: Default value is 0. Range lies from 0 to 4095. 802.1p Priority value: Default value is 0. Range lies from 0 to 7. *** The above 2 settings need to be supported on the network and then configured accordingly on the GXW410x. Incorrect configuration will cause blocked access, which will result in Factory Reset as the only option to renew access. Local RTP port This parameter defines the local RTPRTCP port pair the GXW410x will listen and transmit. It is the base RTP port for channel 0. When configured, channel 0 will use this port _value for RTP and the port_value+1 for its RTCP; channel 1 will use port_value+2 for RTP and port_value+3 for its RTCP and so on. The default value is 5004. Use Random This parameter, when set to Yes, will force random generation of both the local SIP and RTP ports. This is usually necessary when multiple GXW410xs are behind the same NAT. Port Keepalive This parameter specifies how often the GXW410x sends a blank UDP packet to the SIP server in order to keep the “hole” on the NAT open. Default is 20 seconds. interval Use NAT IP... - Page 18 STUN Server IP address or Domain name of the STUN (Simple Traversal of UDP through NATs) server. Firmware This radio button will enable GXW410x to download firmware or configuration file through either Upgrade & TFTP or HTTP. Provisioning Via TFTP Server If selected, the GXW410x will attempt to retrieve new configuration file or new code image from the specified TFTP server at boot time. It will make up to 5 attempts before timeout and then it will start the boot process using the existing code image in the Flash memory. If a TFTP server is ...
- Page 19 NAT related info (INFO level) sent or received SIP message (DEBUG level) SIP message summary (INFO level) inbound and outbound calls (INFO level) registration status change (INFO level) negotiated codec (INFO level) Ethernet link up (INFO level) SLIC chip exception (WARNING and ERROR levels) 10. memory exception (ERROR level) The Syslog uses USER facility. In addition to standard Syslog payload, it contains the following components: GS_LOG: [device MAC address][error code] error message Example: May 19 02:40:38 192.168.1.14 GS_LOG: [00:0b:82:00:a1:be][000] Ethernet link is up NTP server URI or IP address of the NTP (Network Time Protocol) server, which will be used by the phone to synchronize the date and time. Allow DHCP Default value is No. If set to Yes, the NTP server will originate from the DHCP server. Option 42 to override an NTP server Enable Video When set to Yes, GXW410x will start converting video feed received from analog camera to IP packets. In order to view this video feed, please follow instructions given under Video Surveillance Surveillance chapter on page 23. RTSP Port By default it is 554. VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
-
Page 20: Configuring The Fxo Channels
FXO C ONFIGURING HANNELS Configuring the FXO channels on the GXW410x gateway is an easy process. Follow the GUI interfaces. The Device Status page terms are defined in Table 9: FXO Lines Configuration Definitions. An example of the Channel Dialing Configuration is shown in Figure 6. Please note the default is always configured. The user has the option to change the default settings as described in the Table 9. 9: FXO L C D ABLE INES ONFIGURATION EFINITIONS Syntax for Channel Specific Settings: Default: ch18:X; {all channels 1 to 8 are set to use value X} Additional Examples: ch1,36:10;ch2,78:12 {channels 1,3,4,5 and 6 are set to use value 10 while channels 2,7 and 8 are set to use value 12. - Page 21 Wait for Dialtone Default is No. When set to Yes, the gateway will recognize dialtone from the Central Office (CO) before it completes a call. If you can’t make an outbound call, set this is Yes. if this is set to Yes make sure you have configured the dial tone settings correctly in the Channels tab and that there is not any major noise interference in the line. Stage Method Syntax ch18:1; {all channels 1 to 8 are set to value 1 or 2} Stage method can be set to either 1 or 2. Set this parameter to 1 if you need to make a direct PSTN call from a VOIP endpoint. When you set it to 2, you will first dial one of the VOIP channel accounts from the VOIP endpoint, this will result in getting a PSTN line dialtone to then dial out the destination PSTN number. Most implementations require this setting to be configured to 1. Min. Delay before Default is 500ms. This needs to be equal to or greater than the Current Disconnect threshold setting. Once the threshold is reached the gateway can dial out. This parameter should only be Dial PSTN used if there are PSTN line detection issues. Unconditional Call This is an extremely important setting to make sure incoming PSTN calls are picked up and forwarded to the correct VOIP destination. Forward to VOIP: User ID This parameter allows users to configure a User ID or extension number to be automatically dialed upon FXO line offhook.
- Page 22 Caller ID Scheme The GXW410x supports 5 different types of schemes: Bellcore (US standard) ETSIFSK during ringing ETSIFSK prior to ringing with DTAS ETSIFSK prior to ringing with LR ETSIFSK prior to ringing with PR ETSIDTMF during ringing ETSIDTMF prior to ringing with DTAS ETSIDTMF prior to ringing with PR ETSIDTMF prior to ringing with PR 10. SIN 227 BT 11. NTT (Japanese standard) Please check with your PSTN service provider (or traditional PBX specs) for which caller ID scheme they/it support. If you are not sure about which to use please refer to Table 10 (FXO Lines Test Tab Definition). This tool will run an automated test to determine the proper Caller ID Scheme so the gateway can properly detect the Caller ID. Similarly to the cases explained above we can specify a caller ID scheme for each channel independently.
-
Page 23: Table 10: Fxo Line Test Tab Definitions
10: FXO ABLE LINE TEST DEFINITIONS Note: The user can only test the parameters for only one of the PSTN lines at the same time. In all cases please enter the telephone numbers as if the lines were to dial each other locally. For the AC Impedance Test we only need to select the line to be tested by clicking on the AC impedance box corresponding to that line, telephone numbers are optional. Remember that the AC impedance test is usually used to reduce the echo that might be present in the line. For the CPT test (call progress tones) we will test current disconnect as well. You will need 2 telephone numbers to perform the test. You can only perform the test on one line (row) at the same time and it will be the one that has the box checked for testing. This tested line will use another line connected to the gateway to perform the test by calling into it, this is why you will have to enter the telephone number for a second line to help with the test. For CID detection you will need 2 telephone numbers to perform the test. You can only perform the test on one line (row) at the same time and it will be the one that has the box checked for testing. This tested line will use another line connected to the gateway to perform the test by calling into it, this is why you will have to enter the telephone number for a second line to help with the test. To perform the test, please select the line you want to test and the desired test to be performed. Enter the information for this line as well as a second line if necessary. Then click on the update button and then reboot. Log back in and now you should see the information for the line selected as well as the check box already marked already there. Go ahead and start the test now, please wait a few minutes until the test is done. Notes: It is not required to enter a telephone number when testing for impedance, as the system does not place any actual calls for the test. If you log into the Web Interface while the test is running will not interrupt the process. -
Page 24: Table 11: Channels Page Definitions
Apply test results Default is No. If selected on Yes, then all the results from the test will be applied automatically. If you select No you will have to monitor the Syslog output. This is only automatically reserved for very advanced users. Apply test results to all Default is No. If selected on Yes, then all the test results will be applied to all ports on the gateway. If all the lines belong to the same service provider or PBX it will make ports sense to apply the results to all ports. Error Timeout This is the time the gateway will wait to exit the test mode, when something unexpected or an error has occurred. - Page 25 Echo Cancellation When set to Y, Echo cancellation is enabled. Channel specific Setting Channel specific settings mentioned below. DTMF Method This parameter specifies the mechanism to transmit DTMF digits. There are7 modes supported: in audio which means DTMF is combined in audio signal (not very reliable with low bitrate codec), via RTP (RFC2833), or via SIP INFO. Multiple DTMF transmission schemes can be selected. 1 – inaudio 2 – RFC2833 3 – inaudio and RFC2833 4 – SIP Info 5 – inaudio and RFC2833 6 – SIP Info and RFC2833 7 – inaudio, RFC2833, and SIP Info No Key Entry Timeout Default is 4 seconds. ...
-
Page 26: Profiles
Default Yes, No means to use DTMF parameter settings according to DTMF Digit Length, DTMF Digit Volume and DTMF Dial Pause. from RFC2833 or SIP Info DTMF Digit Length Default value is 100ms. Please not that the value will be multiplied by 10ms DTMF Digit Volume Default value is 11dB. DTMF Dial Pause Default value is 100ms. Please note that the value will be multiplied by 10ms. ROFILES Profiles are basically IPPBX / SIP Server configuration templates. If you have more than one IPPBX system or SIP Server that you would like to use with the GXW410x, then you can configure Profile 2 or 3. Note: Make sure you select the correct profile for each channel under Channels PAGE 13: P P D ABLE ROFILE EFINITIONS Activate Profile When set to Yes the SIP Profile is activated. ... - Page 27 Time NAT Traversal This parameter defines whether the GXW410x NAT traversal mechanism will be activated or not. If activated (by choosing “Yes”) and a STUN server is also specified, then the GXW410x will behave according to the STUN client specification. Under this mode, the embedded STUN client inside the GXW410x will attempt to detect if and what type of firewall/NAT it is sitting behind through communication with the specified STUN server. If the detected NAT is a Full Cone, Restricted Cone, or a PortRestricted Cone, the GXW410x will attempt to use its mapped public IP address and port in all of its SIP and SDP messages. If the NAT Traversal field is set to “Yes” with no specified STUN server, the GXW410x will periodically (every 20 seconds or so) send a blank UDP packet (with no payload data) to the SIP server to keep the “hole” on the NAT open. ProxyRequire SIP Extension to notify SIP server that the unit is behind the NAT/Firewall.
-
Page 28: Saving The Configuration Changes
C C AVING ONFIGURATION HANGES When changes are made, press the “Update” button in the Configuration Menu. The GXW410x will display the following screen to confirm that the changes have been saved. To activate changes, reboot or power cycle the GXW410x after all changes are made. R EBOOTING... -
Page 29: Video Surveillance
S IDEO URVEILLANCE The GXW410x gateway can be used with an Analog Surveillance CCD Camera to perform video surveillance function. This application should be used in a LAN environment or when both sides have public IP address. S P IDEO URVEILLANCE ROCEDURES ... -
Page 30: Figure 7: Screen Shot Of Video Surveillance
7: S V S * IGURE CREEN SHOT IDEO URVEILLANCE * PC client side running VLC as monitoring station VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 31: Firmware Upgrade
4. Once the “Firmware Server Path” is set, update the change by clicking the “Update” button. 5. Reboot or power cycle the unit. If the configured upgrade server is found and a new code image is available, the GXW410x will retrieve the new image files by downloading them into the GXW410 gateway’s SRAM. During this stage, the GXW410x gateway’s LED will blink until the checking/downloading process is completed. Upon verification of checksum, the new code image will be saved into the Flash. If TFTP fails for any reason (e.g., TFTP server is not responding, there are no code image files available for upgrade, or checksum test fails, etc), the GXW410x gateway will stop the TFTP process and simply boot using the existing code image in the flash. ... -
Page 32: Download Tftp Server
Firmware upgrade process may take as long as 20 minutes over the Internet, or just 20+ seconds if it is performed on a LAN. Grandstream recommends conducting firmware upgrades in a controlled LAN environment if possible. TFTP S OWNLOAD ERVER For users who do not have a local TFTP server, Grandstream provides a NATfriendly TFTP server on the public Internet for users to download the latest firmware upgrade automatically. Please check the Services section of Grandstream’s Web site to obtain this TFTP server IP address. Alternatively, user can download and install a free TFTP or HTTP server in his LAN for a firmware upgrade. A free Windows version TFTP server can be downloaded from: http://support.solarwinds.net/updates/NewcustomerFree.cfm. Directions for Downloading TFTP Server: 1. Unzip the file and put all of the files under the root directory of the TFTP server. ... -
Page 33: Restore Factory Default Setting
D S ESTORE ACTORY EFAULT ETTING WARNING! Restoring the Factory Default Setting will DELETE all configuration information of the phone. Please BACKUP or PRINT out all the settings before you approach to following steps. Grandstream will not take any responsibility if you lose all the parameters of setting and cannot connect to your VoIP service provider. The ONLY way to restore default factory settings is as follows: 1. Unplug the Ethernet cable. 2. Locate the needle sized hole on the back panel of the gateway next to the Power connection. 3. Enter a thin object in this hole and keep it pressed for about 7 seconds. 4. You will see the Network port LEDs (green and orange) go off and on simultaneously; this ... -
Page 34: Examples Of Gxw410X Configurations
Examples of GXW410x Configurations O : GXW IPPBX SIP S PPLICATION CONNECTED WITH ERVER Scenario: A business with a traditional phone system (with or without broadband access) and an IP PBX or SIP Servers connecting to an Internet Telephone Service Provider (ITSP). Anywhere in the world IPPBX or Server 4 or 8 Lines Ports PSTN PSTN IP/LA IP/WA Cloud Cloud GXW- 410x Grandstream IP Phones PSTN Analog Lines T... - Page 35 CONNECTED WITH ERVER IDEO URVEILLANCE Scenario: The GXW410x offers an additional video surveillance port which can be configured for surveillance. It is the only small business analog gateway that offers this security feature. Branch A – Boston, MA 6 employees...
- Page 36 F : U GXW P IP IP C C PPLICATION SING OMMUNICATION ONFIGURATION Scenario Four: The GXW410x offers an IP to IP pure IP Communications System configuration, where all locations use IP phones. Branch A – Boston, MA 6 employees IPPBX or IPPBX or Internet Internet SIP Server Cloud Cloud Server IP/LAN IP/LAN PSTN PSTN Cloud Cloud 410x 410x Grandstream IP...
