2.2.5 VoIP V2 Loudspeaker Amplifier System Installation and Connection
Options
Figure 2-8
Existing Loudspeaker
Operations Guide
through Figure 2-9 illustrates connection options for the VoIP V2 Loudspeaker Amplifier.
Figure 2-8. V2 Paging Amplifier Connections
See Figure 2-9
See Figure 2-10
Generic Ethernet Switch
1 2
Line-out
Connection
Existing Amplifier
Loudspeaker Amplifier
Figure 2-10. Speaker Out Connection
802.3af Compliant Ethernet Switch
High Power PoE Switch
1 2
011068 Loudspeaker
Loudspeaker Amplifier
(up to 25 watts)
High Power PoE Injector in Box
930375C
1-Sense (+)
2-GND
3-Relay COM
4-Relay NO
5-Line-In(+)
6-Line-In(-)
7-Line-Out(+)
8-Line-Out(-)
9-Spkr Out(+)
10-Spkr Out (-)
Figure 2-9. Line Out Connection
3 4 5 6
IP Phone
(up to 25 watts)
3 4 5 6
VoIP Phone
Installing the VoIP V2 Loudspeaker Amplifier
Loudspeaker Amplifier Setup
Informacast Server
Informacast Server
CyberData Corporation
12
