For Your Safety

These warnings are provided in the interest of safety. You
installing or using the appliance.
It is most important that this instruction book should be retained with the appliance for future
reference. Should the appliance be sold or transferred, always ensure that the book is left with
the appliance in order that the new owner can get to know the functions of the appliance and
the relevant warnings.
During Operation
This appliance has been designed to be operated by
adults and children under supervision. Young children
be allowed to tamper with the controls or
MUST NOT
play near or with the oven.
This appliance
has been designed for cooking
edible foodstuff and to be used for domestic non-
professional purposes only. It must not be used for
any other purpose.
It is dangerous to alter the specification in any way.
For hygiene and safety reasons, this appliance should
be kept clean at all times. A build-up of fats or other
foodstuff could result in a fire.
Accessible parts of this appliance may become hot
when it is in use. Children should be
it has cooled.
Under no circumstances should you attempt to repair
the appliance yourself. Repairs carried out by
unexperienced persons may cause injury or serious
malfunctioning. Refer to your local Zanussi Service
Centre. Always insist on genuine Zanussi spare
parts.
Ensure that all control knobs are in the OFF position
when not in use.
Should you connect any electrical tool to a plug near
this cooking appliance, ensure that electric cables
are not in contact with it and keep them far enough
from the heated parts of this appliance.
If the appliance is out of order, disconnect it from the
electric supply.
MANUFACTURER:
ELECTROLUX HOME PRODUCTS ITALY S.p.A.
Viale Bologna 298 - 47100 FORLI' (Italy)
These instructions are only for the countries stated by the symbol
ENGLISH
until
KEPT AWAY
printed on the front cover of this instruction book.
read them carefully before
MUST
About Installation, Cleaning
and Manteinance
It is mandatory that all operations required for the
installation are carried out by a qualified or competent
person, in accordance with existing rules and
regulations.
Disconnect the appliance from the electrical supply,
before carrying out any cleaning or manteinance
work.
Ensure a good ventilation around the appliance. A
poor air supply could cause lack of oxygen.
Ensure that the gas supply complies with the gas
type stated on the identification label, placed near
the gas supply pipe.
Using a gas cooking appliance will produce heat
and moisture in the room which it has been
installed in. Ensure a continuous air supply,
keeping the air vents in good conditions or
installing a cooker hood with discharge tube.
In case of intensive or long time use of the
appliance, make the ventilation more efficient,
by opening a window or increasing the electric
exhaust fan power.
Once you removed all packaging from the appliance,
ensure that it is not damaged and the electric cable
is in perfect conditions. Otherwise, contact your
dealer before proceeding with the installation.
The manufacturer disclaims any responsability
should all the safety measures not be carried
out.
This appliance complies with the following
E.E.C. Directives:
-
73/23 - 90/683 (Low Voltage Directive);
-
89/336 (Electromagnetical Compatibility Directive);
-
90/396 (Gas Appliances)
-
93/68 (General Directives)
and subsequent modifications.
