Appendix A. Connector Pin Definitions
Table A-3. SFP Slot Pinouts
Pin
Name
1
GND
2
TX_FAULT
3
TX_DISABLE
4
I2C_SDA
5
I2C_SCL
6
MOD_DEF(0)
7
RATESEL
8
RX_LOS
9
GND
10
GND
40
NetVanta 1535P Hardware Installation Guide
Pin
Name
11
GND
12
RX_DAT-
13
RX_DAT+
14
GND
15
VddR
16
VddT
17
GND
18
TX_DAT+
19
TX_DAT-
20
GND
Copyright © 2013 ADTRAN, Inc.
61702595G10-34C
