Physical Descriptions

LED Descriptions

The following table describes LED activity.
LED
STAT
RPS
EPS
LINK/ACT
PoE
VCID
Port LED in
Link/Activity Mode
(1 - 28)
Port LED in PoE Mode
(1 - 24 PoE units only)
Ports 25 through 28 are always in LINK/ACT mode.
18

Table 1. Front Panel LED Descriptions

Color
Off Unit is not receiving power.
Green (flashing) On power up, the STAT LED flashes rapidly for five
seconds, during which time the user may escape to boot
mode from the CONSOLE port.
Green (solid) Power is on and self-test passed.
Red (solid) Power is on, but the self-test failed or the application code
could not be booted.
Off RPS is not connected.
Green (solid) RPS is connected and the internal supply is functioning.
Red (solid) RPS is connected and the internal supply has failed.
Off EPS is not connected.
Green (solid) EPS is connected and the internal supply is functioning.
Red (solid) EPS is connected and the internal supply has failed.
Off Link status/activity is not being displayed.
Green (solid) Link status/activity is being displayed.
Off PoE status is not being displayed.
Green (solid) PoE status is being displayed.
Off VCID is not selected.
Green (solid) VCID is selected. The port LED that corresponds to the
unit's VCID will display green.
Off The port is not connected.
Green (solid) The link is up and the port is enabled.
Amber (flashing) There is activity on the port.
Off The port is not delivering power.
Green (solid) The port is delivering power.
Red (solid) The port has detected a PoE fault.
Copyright © 2013 ADTRAN, Inc.
NetVanta 1535P Hardware Installation Guide
Indication
61702595G10-34C
