APPENDIX A.
The following tables provide the pin assignments for the base unit.

Base Unit Pinouts

Table A-1. CONSOLE Port Pinouts

Pin Name
1 DCD
2 RD
3 TD
4 DTR
5 SG
6 DSR
7 —
8 CTS
9 —

Table A-2. 1000Base-T Gigabit Ethernet Port Pinouts

Pin Name
1 TRD0+
2 TRD0-
3 TRD1+
4 TRD2+
5 TRD2-
6 TRD1-
7 TRD3+
8 TRD3-
61702595G10-34C
CONNECTOR PIN DEFINITIONS
Description
Data Carrier Detect (output)
Receive Data (output)
Transmit Data (input)
Data Terminal Ready (input)
Signal Ground
Data Set Ready Tied to pin 1 (output)
Unused
Clear to Send Tied to pin 1 (output)
Unused
Description
Transmit/Receive Positive
Transmit/Receive Negative
Transmit/Receive Positive
Transmit/Receive Positive
Transmit/Receive Negative
Transmit/Receive Negative
Transmit/Receive Positive
Transmit/Receive Negative
Copyright © 2013 ADTRAN, Inc. 39
