Nady Systems VR-3U Owner's Manual page 5

uH-3 Handheld Mic Transmitter
14 15
13. INPUT VOLUME User adjustable input
level trim-pot
14. INTEGRAL ANTENNA Built-In antenna
15. MIC BALL Windscreen
16. BATTERY COVER Unscrew to insert two
AA alkaline batteries
17. BATTERY COMPARTMENT Holds two
AA alkaline batteries
18. Two AA ALKALINE BATTERIES
19. AUDIO MUTE/ON Slide switch to turn
audio on/off; set to On to un-mute audio
20. LOW BATTERY LED Indicates the batteries
are low (Red)
21. ON/OFF SWITCH Slide power switch
up-down to turn on/off
22. POWER ON LED Indicates TX is on (Green)
16
13 17 18
21
22
19 20
5
