Surround Speakers - Sharp HT-CN550DVW3 Operation Manual

Surround speakers

Type Full range speaker system
7.6 cm (3") speaker
2.0 cm (5/64") super tweeter
Maximum input power 40 W
Impedance 4 ohms
Dimensions Width: 95 mm (3-47/64")
Height: 150 mm (5-29/32")
Depth: 95 mm (3-47/64")
Weight 0.5 kg (1.1 lbs.)/each
Centre speaker
Type Full range speaker system (magnetic shield)
7.6 cm (3") x 2 speakers
2.0 cm (5/64") super tweeter
Maximum input power 80 W
Impedance 8 ohms
Dimensions Width: 250 mm (9-27/32")
Height: 95 mm (3-47/64")
Depth: 85 mm (3-11/32")
Weight 1.1 kg (1.5 lbs.)
Subwoofer
Type Subwoofer system
16.5 cm (6-1/2") subwoofer
Maximum input power 80 W
Impedance 8 ohms
Dimensions Width: 182 mm (7-11/64")
Height: 375 mm (14-49/64")
Depth: 355 mm (13-63/64")
Weight 4.2 kg (9.2 lbs.)
HT-CN550DVW3
ENGLISH
E-54
