Front/surround speakers
2
1
1. Speaker
2. Super Tweeter
3. Speaker Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Centre speaker
1 1
1. Speaker
2. Super Tweeter
3. Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3
Reference page
3
2
Reference page
Subwoofer
1
1. Bass Reflex Duct
2. Woofer
3. Speaker Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Speaker functions
Front speaker:
Reproduces left and right sound (stereo mode) or front surround sound.
Centre speaker:
Reproduces centre surround sound.
Surround speaker:
Reproduces rear surround sound.
Subwoofer:
Reproduces bass sound.
Notes:
Do not allow any objects to fall into or to be placed in the bass reflex ducts.
Front and centre speakers are magnetically shielded.
2 3
Reference page
HT-CN550DVW3
