BRAKE & CLUTCH PEDAL
BRAKE PEDAL
Checking Pedal Free Play
Turn off the engine and depress the brake pedal several
times to deplete the vacuum in the brake system. Gently de-
press the brake pedal by hand and measure the distance it
moves until slight resistance is felt. If the free play is more
or less than specified, have the brakes adjusted by a
Ssangyong Dealer or Ssangyong Authorized Service Opera-
tion.
Brake pedal free play 1 ~ 4 mm
Page 19
CLUTCH PEDAL
Checking Pedal Free Play
Depress the pedal by hand until clutch resistance is felt; en-
sure free play is within specification.
If the free play is more or less than specified, have the clutch
or linkage adjusted by Ssangyong Dealer or Ssangyong Au-
thorized Service Operation.
Clutch pedal free play 5 ~ 10 mm
SERVICE AND MAINTENANCE
