FLIR SR-100 PT Installation And Operation Manual
Sr-pt thermal camera
Hide thumbs
Also See for SR-100 PT:
- Installation and operation manual (46 pages) ,
- Brochure & specs (5 pages) ,
- Installation and operation manual (40 pages)
Table of Contents
Advertisement
Quick Links
S
R
-
P
S
R
-
P
I
n
s
t
a
l
l
a
t
i
I
n
s
t
a
l
l
a
t
FLIR Systems, Inc.
70 Castilian Drive
Goleta, CA 93117
Phone: 888.747.FLIR
(888.747.3547)
International: +1.805.964.9797
www.flir.com
427-0027-01-10 Rev. 100
T
T
h
e
r
m
T
T
h
e
r
m
o
n
a
n
d
O
i
o
n
a
n
d
O
© 2009 FLIR Systems, Inc.
a
l
C
a
m
a
l
C
a
m
p
e
r
a
t
i
o
n
p
e
r
a
t
i
o
n
Camera Models
SR-100 PT
SR-35 PT
e
r
a
e
r
a
M
a
n
u
a
l
M
a
n
u
a
l
SR-50 PT
SR-19 PT
Page 1 of 21
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for FLIR SR-100 PT
Summary of Contents for FLIR SR-100 PT
- Page 1 FLIR Systems, Inc. Camera Models 70 Castilian Drive Goleta, CA 93117 SR-100 PT SR-50 PT Phone: 888.747.FLIR (888.747.3547) International: +1.805.964.9797 SR-35 PT SR-19 PT www.flir.com 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 1 of 21...
-
Page 2: Flir Systems Inc
Diversion contrary to US law is prohibited. US Department of Commerce authorization is not required prior to export or transfer to foreign persons or parties unless otherwise prohibited. 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 2 of 21... -
Page 3: Table Of Contents
Ground Connection........................7 Accessing the Electrical Connections ..................8 Power and Serial connections....................10 Cable Leads.........................10 Input Power..........................10 SR-100 PT Connections ......................11 SR-19, SR-35, SR-50 Connections ..................12 Assembly of Camera to Pan/Tilt base ..................13 Mounting the SR-PT Camera......................14 Camera Operation ........................17 IR Functions..........................17 Operational Temperatures ......................17... -
Page 4: Warnings And Cautions
Important! All thermal imaging systems are subject to export control. Please contact FLIR for export compliance information concerning your application or geographic area. 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 4 of 21... -
Page 5: Introduction
SR-PT thermal imagers need no light at all. SR-PT Camera Models The cameras are available with a choice of lenses for short-, medium- and long-range surveillance capability. 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 5 of 21... -
Page 6: Camera
Black Hot palette displays warmer objects as black or dark rather than white or light shades. Additional pseudo color palettes are available using the application software supplied with the camera. 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 6 of 21... -
Page 7: Installation
Typically the Earth ground connection will be part of the power cable bundle. Internal Ground Earth Ground connection External Chassis Ground connection Power Supply shield/drain wire Figure 1: Earth Ground Connection 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 7 of 21... -
Page 8: Accessing The Electrical Connections
This connector can be detached from the unit by gently pulling on it. When replacing it, be careful to maintain the proper orientation when connecting the leads and reinserting the connector to the camera. 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 8 of 21... - Page 9 When the sealing nut is tightened, the plug should be flush with the back of the sealing nut. 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 9 of 21...
-
Page 10: Power And Serial Connections
The SR-PT cameras operate 24VAC power (nominal). The cameras provide screw-terminals for receiving tinned leads for input power. The power cable should be twisted pair or triple, with an 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 10 of 21... -
Page 11: Sr-100 Pt Connections
RS-232: Receive Data (RD) Not used Not used Not used Ground Black (2 wires) -Voltage In Black (single wire) AC B +Voltage In White AC A Table 1: SR-100 Screw Terminals 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 11 of 21... -
Page 12: Sr-19, Sr-35, Sr-50 Connections
Black (single wire) AC A Power White AC A Note: Be sure to connect the ground to the lug inside the rear cover Table 2: Power and Serial Pin Designations 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 12 of 21... -
Page 13: Assembly Of Camera To Pan/Tilt Base
Set screws (2 on each side) The torque for the #8 set screws should be 10-15 in- lbs. 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 13 of 21... -
Page 14: Mounting The Sr-Pt Camera
Phillips crews and lifting the module. Attach the base of the system to the included base plate with the three flathead 10-32 x 1/2-inch screws and washers (supplied). 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 14 of 21... - Page 15 Align the pan and tilt part number with the alignment label of the base and then attach the pan and tilt to the base with three 1/4-20 nuts and washers (supplied). 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 15 of 21...
- Page 16 NOTE: Switch settings have no effect on Coaxitron control signals. The SR-PT will sense and automatically select input from Coaxitron control signals in either standard or extended mode. For more information please refer to the Pelco ES3012 Series Esprit Manual 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 16 of 21...
-
Page 17: Camera Operation
Camera Operation The camera supports a subset of the Pelco D functions. If you have a question regarding installation or operation of your SR-PT camera, contact FLIR Systems, Inc Customer Support, using the contact information at the front of this manual. -
Page 18: Appendix
APPENDIX 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 18 of 21... - Page 19 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 19 of 21...
- Page 20 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 20 of 21...
- Page 21 427-0027-01-10 Rev. 100 © 2009 FLIR Systems, Inc. Page 21 of 21...
