  • Page 1: User Manual

    User Manual Minoltafax 1100 www.minoltaeurope.com The essentials of imaging...

  • Page 2: Table Of Contents

    Instructions for personal and operational safety ......1-5 Approval symbol................1-7 Unpacking, installation, setup Unpacking the fax machine............2-1 Machine layout ................2-2 Control panel of Minoltafax 1100 ............2-3 Installing the fax machine ............2-5 Ambient requirements ..............2-5 Location...................2-5 Space requirement................2-6 Storage of consumables ..............2-6 Setting up the fax machine ............2-7...
  • Page 3 Setting the one-touch keys............3-8 Storing a number under a one-touch key ........3-9 Altering one-touch key allocation..........3-10 Deleting the allocation of a one-touch key........3-11 Printing a list of allocated one-touch keys ........3-12 Setting up the directory ............. 3-13 Entering numbers into the directory..........
  • Page 4 Sending a document overseas ..........4-17 Reducing the fax transmission speed ...........4-17 Activating redial function ............4-18 Setting the quantity of redial attempts...........4-18 Starting manual redial function............4-19 Receiving faxes Receiving faxes automatically .............5-1 Receiving faxes manually ............5-2 Combination with an answering machine ........5-3 Receiving selected faxes..............5-4 Memory reception during printer problem .........5-5 ......................5-5...
  • Page 5 Caring for the machine .............. 10-2 Cleaning the housing..............10-2 Cleaning document transport rollers 1 and 2........ 10-2 10.3 Technical data................10-4 Minoltafax 1100 ................10-4 Optional accessory ............... 10-5 10.4 CE emblem (conformity declaration)........10-6 10.5 Index .................... 10-7...

  • Page 6: Introduction

    This fax machine is approved for use in public telephone networks and is compatible to other fax machines of transmission standard 3. This manual will enable you to achieve maximum results of your Minoltafax 1100 because it contains detailed information to the following subjects: l Safe operation of your fax machine.
  • Page 7 Introduction This documentation must not be reproduced, transferred, copytyped, stored in an archive or translated without the explicit prior permission in writing by Minolta Co. Ltd. The manufacturer reserves the right to modify this manual. MF 1100 Rev. 1.1.1/07.06.99...

  • Page 8: Guide Through The Manual

    This is where you will learn how to use the telephone unit. Specific machine settings This is where you will learn how to "tailor" the settings of your Minoltafax 1100 to suit your own special requirements. Trouble-shooting This is where you will learn how to identify and rectify simple problems.

  • Page 9: Short Description Of Autography And Symbols

    Introduction Short description of autography and symbols Various autography and symbols are used in this manual to express various situations. The examples below will enable you to identify the various situations and handle them accordingly. CAUTION This is a warning! A warning makes you aware of a hazard that can cause death, personal injury or damage to the machine due to incorrect operation.

  • Page 10: Safe Operation Of Your Fax Machine

    Introduction Safe operation of your fax machine Instructions for personal and operational safety Personal injury, electrical shocks or even fires can result from incorrect operation. Before unpacking your fax machine, please read the following safety precautions to ensure your personal safety and also the operational safety of your fax machine.
  • Page 11 Introduction Í Do not interrupt the power supply while the machine is transmitting or printing. Í Do not place magnetic objects near the machine. Í Do not use inflammable aerosols, liquids or gases near the machine. Í Do not remove any safety devices, and do not alter the machine’s design.

  • Page 12: Approval Symbol

    Introduction Approval symbol The Minoltafax 1100 fulfils the fax requirements according to CTR 21 and DTS. The machine bears the EMV symbol as proof that it complies to requirements of EN 50081-1 and EN 50082-1. Machines equipped with the "GS"...
  • Page 13 Introduction MF 1100 Rev. 1.1.1/07.06.99...

  • Page 14: Unpacking, Installation, Setup

    Unpacking, installation, setup Unpacking, installation, setup Unpacking the fax machine CAUTION Plastic packaging is hazardous for small children! Í Please keep the packaging out of reach of small children. Remove the fax machine and its accessories from the carton. Fax machine Paper support Instruction manual Telephone handset...

  • Page 15: Machine Layout

    Unpacking, installation, setup Machine layout Paper support Document support Document guide Control panel Document output Paper output Ringer volume Monitoring volume Document sensor Document transport roller 1 Document transport roller 2 Document release lever MF 1100 Rev. 1.1.1/07.06.99...

  • Page 16: Control Panel Of Minoltafax 1100

    Unpacking, installation, setup Control panel of Minoltafax 1100 2 3 4 6 7 8 Item Designation Function NUMERIC KEYPAD To enter figures or letters MENU To scroll through the various menus To confirm data / selections in the menus MEMORY...
  • Page 17 Unpacking, installation, setup Item Designation Function DIRECTORY To scroll through the directory SEARCH To search for a specific directory number START To start a function: Transmit Receive COPY To start: A copy function A list print-out STOP To interrupt a function and eject a document REDIAL/P To re-dial the number last dialled, and to insert a pause between two digits of a number...

  • Page 18: Installing The Fax Machine

    Unpacking, installation, setup Installing the fax machine Ambient requirements Optimum ambient requirements for the printer are: l Temperatures between 5°C and 35°C (Fluctuations max. 10°C per hour) l Humidity between 15% and 85% (Fluctuations max. 20% per hour). Location The installation location must fulfil the following requirements: l Dry and dust-free.

  • Page 19: Space Requirement

    Protected from direct sunlight or heat. l In a cool, dry and dust-free place. l Our of the reach of small children. A small box is located inside the Minoltafax 1100 in which a spare ink cartridge can be stored. MF 1100...

  • Page 20: Setting Up The Fax Machine

    Unpacking, installation, setup Setting up the fax machine Connecting the fax machine Slide the plastic noses on the paper support in the available slots. Connect the handset to the available connection. Connection for handset Connect the fax machine to the telephone connection.

  • Page 21: Installing The Ink Cartridge

    Unpacking, installation, setup Installing the ink cartridge CAUTION Damage to ink cartridge! If handled incorrectly, the printing head on the ink cartridge can be damaged. The ink cartridge can then no longer be used. Í Do not touch the printing head on the ink cartridge. Í...
  • Page 22 Unpacking, installation, setup Insert the ink cartridge in the cartridge holder. Gently press the ink cartridge forwards. The ink cartridge must engage with an audible click. Close the control panel cover. The display will show NEW CARTRIDGE. If NEW CARTRIDGE does not appear in the display? Í...

  • Page 23: Re-Aligning The Printer

    Unpacking, installation, setup Re-aligning the printer Re-align the printer. Press the [MENU] key 7 times. 7: SET PRINTER ? Confirm your choice by pressing the [SET] key. Press the [MENU] key. Confirm 2: ALIGN ? your choice by pressing the [SET] key.

  • Page 24: Inserting Paper

    Unpacking, installation, setup Inserting paper Insert up to 50 sheets of paper (75 g/m ) in the paper feeder. Use only good quality paper with the following qualities: á Paper formats: A4 (210 × 297 mm), Letter (216 × 279 mm), Legal size (216 ×...
  • Page 25 Unpacking, installation, setup Slide the left paper guide against the paper. Paper- guide Close the paper support. 2-12 MF 1100 Rev. 1.1.1/07.06.99...

  • Page 26: Setting The Ringer Volume

    Unpacking, installation, setup Setting the ringer volume Set the ringer volume as required. The volume selector switch is at the left side of the machine. Í Select one of the settings: Ringer loud Ringer normal Ringer silent Ringer volume Setting the monitoring volume Set the monitoring volume as required.
  • Page 27 Unpacking, installation, setup 2-14 MF 1100 Rev. 1.1.1/07.06.99...

  • Page 28: Individual Fax Machine Settings

    Individual fax machine settings Please observe! You should read these pages thoroughly and become familiar with your Minoltafax 1100 in order to be able to set the machine to your individual requirements. List of letters, symbols and digits Letters, symbols and digits can be entered via the numerical keys. All characters accessible by the numerical keys are listed in three groups.

  • Page 29: Entering Letters And Digits

    Individual fax machine settings Entering letters and digits When it is possible to freely select a character, a black square containing the letter "A" will appear at the right end of the display. Enter a name via the numerical keys. Select the character group via the [DIRECTORY] arrow key.

  • Page 30: Correcting An Entered Character

    Individual fax machine settings Correcting an entered character If you enter a wrong character, it can be easily corrected as follows: Press one-touch key [4 - CURSOR MUnTER LEFT], to position the cursor on the character to be corrected. Select the correct character press the one-touch key [0 - DELETE] to delete the wrong character.

  • Page 31: Cancelling A Procedure

    Individual fax machine settings Cancelling a procedure Press the [STOP] key to: Cancel a started procedure (fax transmission, photocopy, etc.). Leave a menu and return to the standard display. Cancel a wrong entry. To eject an inserted document. In order to carry out the above functions: ➜...

  • Page 32: Setting Sender Identification Data

    Individual fax machine settings Setting sender identification data Please program your sender identification. The receiver will then know from which machine an incoming fax was transmitted. Press the [MENU] key 6 times. 6: FAX SET-UP ? Confirm your choice via the [SET] key.
  • Page 33 Individual fax machine settings For PBX mode only CALL No. 0n Enter your PBX number (max. 4 digits). Confirm your choice via the [SET] key. A beep will be heard. The setting is now stored. Press the [STOP] key to return to 08 06.

  • Page 34: Setting The Date And Time

    Individual fax machine settings Setting the date and time The date and time are shown in the standard display of the machine. The date and time will also appear in the header of every outgoing fax and generated report, as well as in the footer of every incoming fax. Press the [MENU] key 6 times.

  • Page 35: Setting The One-Touch Keys

    Individual fax machine settings Setting the one-touch keys The Minoltafax 1100 is equipped with 10 one-touch keys. Each key can be programmed with a fax or number which is frequently called. One-touch keys These one-touch keys offer: One-touch number dialling.

  • Page 36: Storing A Number Under A One-Touch Key

    Individual fax machine settings Storing a number under a one-touch key Store a frequently called number under one of the one-touch keys. You can then call this number with a single touch of the key. Press the [MENU] key twice. 2: SET ONETOUCH ? Confirm your choice via the [SET] key.

  • Page 37: Altering One-Touch Key Allocation

    Individual fax machine settings Altering one-touch key allocation The allocation of a one-touch key can be easily altered, for example, when the number or name must be changed. Press the [MENU] key twice. 2: SET ONETOUCH ? Confirm your choice via the [SET] key.

  • Page 38: Deleting The Allocation Of A One-Touch Key

    Individual fax machine settings Deleting the allocation of a one-touch key Delete the allocation of a one-touch key if you want to store a different number under the vacant key at a later date. Press the [MENU] key twice. 2: SET ONETOUCH ? Confirm your choice via the [SET] key.

  • Page 39: Printing A List Of Allocated One-Touch Keys

    Individual fax machine settings Printing a list of allocated one-touch keys Print out a list showing the detailed allocation of each one-touch key. Press the [MENÜ] key twice. 2: SET ONETOUCH ? Press the [COPY] key. ONETOUCH LIST A list of the one-touch keys will be printed.

  • Page 40: Setting Up The Directory

    Individual fax machine settings Setting up the directory The Minoltafax-Fax is equipped with an electronic directory in which up to 50 numbers can be stored. Arrow keys Search [DIRECTORY] This directory enables: Administration of up to 50 numbers. (new entries, alterations, deletion) Printing a list of all entries in the directory.

  • Page 41: Entering Numbers Into The Directory

    Individual fax machine settings Entering numbers into the directory You can store up to 50 entries in the electronic directory. Press the [SEARCH] key. SEARCH : n Press the [*] key. Enter the number (max. 32 digits). 1234 123456n Confirm your choice via the [SET] key.

  • Page 42: Altering A Directory Number

    Individual fax machine settings Altering a directory number Altering or correcting an entry in the directory. Select the entry you wish to alter via MUSTER the [DIRECTORY] arrow keys. Confirm your choice via the [SET] key. Alter the designation of the number. MUnTER Confirm your choice via the [SET] key.

  • Page 43: Deleting A Directory Number

    Individual fax machine settings Deleting a directory number Deleting stored data from the directory. Select the [DIRECTORY] entry to MUSTER be deleted via the arrow keys. Press the one-touch key DELETE ? [0 - DELETE]. Confirm your choice via the [SET] key. A beep will be heard.

  • Page 44: Calling Statistics Of Directory Number

    Individual fax machine settings Calling statistics of directory number Select the required [DIRECTORY] MUSTER entry via the arrow keys. Press the one-touch key MUSTER [5 - CURSOR RIGHT] to call additional directory information: 1234 123456 ❍ Designation of number ❍ Number ×...

  • Page 45: Printing List Of Directory Entry

    Individual fax machine settings Printing list of directory entry A convenient list of all entries stored in the directory can be printed. Select a [DIRECTORY] entry MUSTER via the arrow keys. Press the [COPY] key while a ‘ DIRECTORY LIST ‘ directory entry is shown in the display.

  • Page 46: Transferring A Directory Entry To A One-Touch Key

    Individual fax machine settings Transferring a directory entry to a one-touch key A directory entry can be transferred to a one-touch key. When transferring, the directory entry will be automatically deleted from the directory. Select the entry to be transferred to MUSTER a one-touch key via the [DIRECTORY] arrow keys.

  • Page 47: Switching Activity Report On/Off

    Individual fax machine settings Switching activity report on/off Switching on the activity report An automatic print-out of the activity report can be generated. You can choose between a daily print-out or an automatic print-out of the activity report after every respective 20 transmissions. Press the [MENU] key six times.

  • Page 48: Switching Off The Activity Report

    Individual fax machine settings Switching off the activity report The automatic activity report can also be switched off. Press the [MENU] key six times. 6: FAX SET-UP ? Confirm your choice via the [SET] key. Press the [MENU] key three times. 4: ACT.
  • Page 49 Individual fax machine settings 3-22 MF 1100 Rev. 1.1.1/07.06.99...

  • Page 50: Sending Documents By Fax

    Sending documents by fax Sending documents by fax Please observe the following! Characteristics of documents to be transmitted Up to 20 documents (with same format and thickness) can be placed in the document feeder. The documents must not be larger or smaller than the following dimensions: Maximum document width Minimum document width...

  • Page 51: Interrupting A Procedure

    Sending documents by fax Interrupting a procedure Pressing the [STOP] key will: Stop a started procedure (fax transmission, photocopy, etc.). Leave the menu and return to the standard display. Cancel wrongly entered data. Eject an inserted document. If you wish to carry out the above functions: ➜...

  • Page 52: Inserting A Document

    Sending documents by fax Inserting a document Place up to 20 sheets in the document feeder. Use only normal paper of good quality as follows: ✔ Paper thickness: Single document 0,05 to 0,15 mm Numerous documents 0,08 to 0,13 mm (per document) Insert the document with its face downwards in the document feeder.

  • Page 53: Setting The Resolution And Contrast

    Sending documents by fax Setting the resolution and contrast The Minoltafax 1100 enables you to adjust the resolution and contrast in numerous stages. This will allow optimum transmission quality with an optimum transmission duration. Setting the resolution for present transmission...

  • Page 54: Permanently Setting The Transmission Resolution

    Sending documents by fax Permanently setting the transmission resolution The resolution of the Minoltafax 1100 in standby mode can be set via the software switches. Press the [MENU] key six times. 6: FAX SET-UP ? Confirm your choice via the [SET] key.

  • Page 55: Setting The Contrast

    Sending documents by fax Setting the contrast The contrast of a fax transmission can be set via the software switches. Press the [MENU] key six times. 6: FAX SET-UP ? Confirm your choice via the [SET] key. Press the [MENU] key twice. 3: FEATURE SW.

  • Page 56: Sending A Document

    Sending documents by fax Sending a document Dialling the number via the numerical keys The receiving fax machine can be dialled via the numerical keys. Insert the document into the STANDARD document feeder and adjust the document guide accordingly. If required, select the required STANDARD transmission quality via the [RESOLUTION] key.

  • Page 57: Dialling A Number Via Redial

    Sending documents by fax Dialling a number via redial The last dialled number can be redialled via redial. Insert the document into the STANDARD document feeder and adjust the document guide accordingly. If required, select the required STANDARD transmission quality via the [RESOLUTION] key.

  • Page 58: Dialling A Number Via A One-Touch Key

    Sending documents by fax Dialling a number via a one-touch key A number can be called via a one-touch key. Insert the document into the STANDARD document feeder and adjust the document guide accordingly. If required, select the required STANDARD transmission quality via the [RESOLUTION] key.

  • Page 59: Dialling A Number Via The Directory

    Sending documents by fax Dialling a number via the directory A number can be selected from the electronic directory for immediate dialling. Insert the document into the STANDARD document feeder and adjust the document guide accordingly. If required, select the required STANDARD transmission quality via the [RESOLUTION] key.

  • Page 60: Dialling And Number And Monitoring A Call

    Sending documents by fax Dialling and number and monitoring a call It is possible to dial a number and monitor the fax transmission. Insert the document into the STANDARD document feeder and adjust the document guide accordingly. If required, select the required STANDARD transmission quality via the [RESOLUTION] key.

  • Page 61: Setting Page Count Function

    Sending documents by fax Setting page count function A page count function can be activated so that numerous pages will be received at the other end with individual page numbers. P. 1/3 P. 2/3 P. 3/3 Insert the document into the STANDARD document feeder and adjust the document guide accordingly.

  • Page 62: Delayed Document Transmission

    Sending documents by fax Delayed document transmission Setting delayed document transmission The timer can be programmed to send a fax at a later time. Insert the document into the STANDARD document feeder and adjust the document guide accordingly. If required, select the required STANDARD transmission quality via the [RESOLUTION] key.

  • Page 63: Altering Transmission Delay Time

    Sending documents by fax Altering transmission delay time The timer for a delayed fax transmission can be altered. Press the [MENU] key three 3: TIMER Tx. ? times. Confirm your choice via the [SET] key. Press the [MENU] key once. CHANGE ? Confirm your choice via the [SET] key.

  • Page 64: Deleting Transmission Delay Time

    Sending documents by fax Deleting transmission delay time The timer for a delayed fax transmission can be deleted. Press the [MENU] key three 3: TIMER Tx. ? times. Confirm your choice via the [SET] key. Press the [SET] key. CANCEL ? A beep will be heard.

  • Page 65: Automatic Print-Out Of Delayed Transmission Report

    Sending documents by fax Automatic print-out of delayed transmission report It is possible to receive a printed report of a delayed transmission. This report will enable you to check whether the delayed transmission was successfully carried out. Press the [MENU] key six 6: FAX SET-UP ? times.

  • Page 66: Sending A Document Overseas

    Sending documents by fax Sending a document overseas When a fax is sent over extremely long distances, the transmission quality can be impaired by interference in the telephone lines. Interference can be avoided by reducing the fax transmission speed. Reducing the fax transmission speed Insert the document into the STANDARD document feeder and adjust the...

  • Page 67: Activating Redial Function

    Sending documents by fax Activating redial function If it is not possible to make a connection, the number will be automatically redialled after 3 minutes. It is also possible to manually activate the redial function. Setting the quantity of redial attempts Setting the quantity of automatic redial attempts if the receiving fax machine cannot be contacted.

  • Page 68: Starting Manual Redial Function

    Sending documents by fax Starting manual redial function A redial function can be manually started. ➜ Press the [REDIAL/P] key. The redial function will now start. Rev. 1.1.1/07.06.99 MF 1100 4-19...
  • Page 69 Sending documents by fax 4-20 MF 1100 Rev. 1.1.1/07.06.99...

  • Page 70: Receiving Faxes

    Is the incoming call a manual fax transmission or a voice call? The Minoltafax 1100 will not switch over to auto fax mode, but will allow the fax machine to ring a further seven times. If the incoming call remains unanswered, your machine will automatically switch over to auto fax mode.

  • Page 71: Receiving Faxes Manually

    Is the incoming call an automatic fax transmission? You will hear a fax machine signal. The Minoltafax 1100 will recognise the incoming signal and automatically start receiving the fax transmission. If software switch 54 has been set at 00 (OFF), your fax machine will not start automatically.

  • Page 72: Combination With An Answering Machine

    E-MODE = ANSWER appears in the display. Is the incoming call an automatic fax transmission? You will hear a fax machine signal. The Minoltafax 1100 will recognise the incoming signal and automatically start receiving the fax transmission. Is the incoming call a voice call? The connect answering machine will accept the call after the programmed amount of rings and send your answer message.

  • Page 73: Receiving Selected Faxes

    Receiving faxes Receiving selected faxes Incoming faxes will only be received if the sender number is programmed as a one-touch number in your fax machine and the station identification has been correctly programmed. The number of the calling machine is not a one-touch number? The incoming fax transmission will be automatically stopped as soon as RECEIVE appears in the display.

  • Page 74: Memory Reception During Printer Problem

    Receiving faxes Memory reception during printer problem If the paper runs out, or the ink cartridge becomes empty, your Minoltafax 1100 will store the incoming transmission data. The memory reception can store up to 34 pages, depending on the original document.

  • Page 75: Calling A Fax Transmission (Polling)

    Receiving faxes Calling a fax transmission (Polling) A fax transmission can be called from another fax machine as long as the other machine has been programmed accordingly. Press the [MENU] key. Confirm 1: POLLING Rx. ? your choice via the [SET] key. Dial the number of the other 1234 123456 fax machine:...

  • Page 76: Receiving A Fax With Size Reduction

    Receiving a fax with size reduction If a transmitted fax is longer than the size of your paper, your Minoltafax 1100 will normally print the incoming fax on two pages. You can prevent this by setting your fax machine to automatically print incoming faxes at a size reduction ratio of 90%, 84% or 70%.

  • Page 77: Fax Machine With External Telephone

    Receiving faxes Fax machine with external telephone If you are operating your Minoltafax 1100 together with an external telephone apparatus and you answer a fax machine by phone, you must manually transfer this fax transmission to your fax machine. Transferring an incoming fax transmission from your external telephone to your fax machine.

  • Page 78: Copying A Document

    Copying a document Copying a document Making a single copy It is possible to copy a document with the Minoltafax 1100. Insert the document with its face STANDARD downwards in the document feeder. The display will show the present resolution setting.

  • Page 79: Copying A Document With Size Reduction

    Copying a document Copying a document with size reduction Copying a document with a copy reduction factor of up to 70%. Press the [MENU] five times. 5: REDUCTION ? Confirm your choice via the [SET] key. Select the required reduction factor REDUCTION OFF via the [MENU] key.

  • Page 80: Using The Telephone

    Using the telephone Using the telephone Making a phone call A phone call can be carried out as follows: Method 1: Press the [MONITOR] key. Dial the required number: ❍ Manually ❍ Via one-touch key ❍ Via directory ❍ Via redial Is your fax machine connected to a PBX system? ➜...

  • Page 81: Receiving A Telephone Call

    Using the telephone Receiving a telephone call Receive a phone call as follows: When the telephone rings, pick up the handset. Answer the call. When the conversation is finished, place the handset on its hook. MF 1100 Rev. 1.1.1/07.06.99...

  • Page 82: Dialling A Number

    Using the telephone Dialling a number Dialling a number via the numerical keys. A number can be dialled via the numerical keys. ➜ Enter the required number via the 1234 123456 numerical keys. Is your fax machine connected to a PBX system? ➜...

  • Page 83: Dialling A Number Via The Directory

    Using the telephone Dialling a number via the directory A number can be dialled via the electronic directory. ➜ Select the entry in the directory via MUSTER the [DIRECTORY] arrow keys. Press the [START] key to start the dialling function. Searching for a number in the directory A search function can be carried out in the directory to find a stored number.

  • Page 84: Putting A Call On Hold

    Using the telephone Putting a call on hold It is possible to put a call on hold so that nothing can be heard at the opposite end. Method 1: Press the [HOLD] key during the conversation. The call will be put on hold. Place the handset on the hook.

  • Page 85: Operator Call

    Using the telephone Operator call It is possible to make an operator call immediately after sending or receiving a fax. Please observe the following: If you pick up the handset and place it back on the hook, the "operator call" feature will be cancelled. If no-one picks up the phone at the other end during the long signal tone, the "operator call"...

  • Page 86: Setting Specific Features

    Setting specific features Setting specific features Using software switches Setting the software switches Adjusting the fax machine to your requirements via software switches. Press the [MENU] key six 6: FAX SET-UP ? times. Confirm your choice via the [SET] key. Press the [MENU] key twice.

  • Page 87: Printing List Of Software Switches

    Setting specific features Printing list of software switches It is possible to print a list of the present software settings. Press the [MENU] key six 6: FAX SET-UP ? times. Confirm your choice via the [SET] key. Press the [MENU] key twice. 3: FEATURE SW.

  • Page 88: List Of Software Switches

    Setting specific features List of software switches Description Selection Default setting Pause duration 2 sec. 3 sec. 4 sec. 12 sec. Quantity of redial attempts during later transmission with timer function (3 to 4 minute intervals) 11 x Quantity of redial attempts during normal transmission 11 x Quantity of call signals...
  • Page 89 Setting specific features Description Selection Default setting Selection of printer paper Letter Legal size Selective transmission reception Resolution STANDARD FINE SUPER-FINE GRAY TONE Last setting Contrast NORMAL LIGHT Report print-out after delayed timer transmission ON (every transmission) ON (with errors only) Half-tone quality relative to Fast transmission transmission speed...

  • Page 90: Switching On Power Save Mode

    Switching on power save mode The power save mode will reduce the energy consumption of the Minoltafax 1100 in standby mode from approx. 5.7 W to approx. 1.7 W. The power save mode will activate itself if during the last 5 minutes:...
  • Page 91 Setting specific features MF 1100 Rev. 1.1.1/07.06.99...

  • Page 92: Trouble-Shooting

    Trouble-shooting Trouble-shooting If a problem occurs during fax operation, check the list of possible problem causes. If the problem cannot be found in the list, please contact your local service centre. General problems Problem description Possible cause / solution The machine will not switch on. The power plug is not in the power Page 2-7 socket.

  • Page 93: Problems When Sending A Fax

    Trouble-shooting Problems when sending a fax Problem description Possible cause / solution Fax transmission is not possible. The document has not been drawn Page 4-3 into the machine. The receiving fax machine is not – ready to receive. The receiving fax machine is been –...

  • Page 94: Problems With Telephone Handset

    Trouble-shooting Problems with telephone handset Problem description Possible cause / solution Dialling tone cannot be heard when The telephone cable is not correctly Page 2-7 picking up the handset. connected. The caller can only be heard very The monitoring function is set at Page 2-13 quietly through the loudspeaker.

  • Page 95: Rectifying Problems

    Trouble-shooting Rectifying problems Removing a jammed document A document is jammed in the fax machine when the display shows DOCUMENT JAM. Fold the control panel forwards. Press and hold the green document release lever while pulling the jammed document slowly upwards out of the machine.

  • Page 96: Removing A Paper Jam

    Trouble-shooting Removing a paper jam Printer paper is jammed in the fax machine when the display shows CHECK PAPER. Fold the paper cover forwards. Pull the jammed paper slowly upwards out of the machine. Close the paper cover. Press the [PRINTER RESET] key. CHECK PAPER ! The standard display will appear.

  • Page 97: Renewing The Ink Cartridge

    Trouble-shooting Renewing the ink cartridge CAUTION Damage to ink cartridge! If handled incorrectly, the printer head on the ink cartridge can be damaged. The ink cartridge can then no longer be used. ➜ Do not touch the printer head on the ink cartridge. ➜...
  • Page 98 Trouble-shooting Remove the protection strips from the new ink cartridge. Insert the new ink cartridge in the cartridge holder. Gently press the ink cartridge forwards. The ink cartridge must engage with an audible click. Close the control panel cover. The display will show NEW CARTRIDGE.

  • Page 99: Re-Aligning The Printer

    Trouble-shooting Re-aligning the printer Re-align the printer as follows: Press the [MENU] key seven times. 7: SET PRINTER ? Confirm your choice by pressing the [SET] key. Press the [MENU] key. Confirm 2: ALIGN ? your choice by pressing the [SET] key.

  • Page 100: Cleaning The Printer Head Nozzles

    Trouble-shooting Cleaning the printer head nozzles Clean the printer head nozzles if the print-out is no longer of optimum quality. Press the [MENU] key seven times. 7: SET PRINTER ? Confirm your choice by pressing the [SET] key. Press the [SET] key. 1: CLEAN NOZZLES ? A test page will be printed out.

  • Page 101: Error Codes In The Printed Reports

    Trouble-shooting Error codes in the printed reports Error codes will be printed on the activity reports and after delayed timer transmissions. These error codes will help you to identify and rectify any problems. Error code Description The fax transmission was successful. No answer from the receiving fax machine.

  • Page 102: Annex

    Photocopying function (up to 50 identical copies) ❍ Selective reception function. The Minoltafax 1100 is approved for connection to Telecom public telecommunication networks and to other fax machines of transmission compatibility group 3. Minoltafax 1100 – For office personnel with high demands! Rev.

  • Page 103: Caring For The Machine

    Annex 10.2 Caring for the machine Cleaning the housing Clean the fax machine housing regularly to prevent excessive collection of dust. ➜ Wipe the housing with a soft cloth, If necessary, the cloth can be slightly soaked with a neutral household cleansing detergent. CAUTION Damage to apparatus due to using wrong cleansing substance! The housing can be damaged when cleaning with substances containing...
  • Page 104 Annex Clean document transport rollers 1 and 2 with a soft cloth slightly soaked with a neutral household cleansing substance. Document Document transport roller 2 transport roller 1 Close the control panel. The display will show OLD CARTRIDGE ? Confirm this via the [SET] key. OLD CARTRIDGE ? The standard display will appear.

  • Page 105: Technical Data

    Annex 10.3 Technical data Minoltafax 1100 General Type Desktop fax machine Compatibility Group 3 Transmission line Public telephone network and PBX system Modem speed 14400, 12000, 9600, 7200, 4800, 2400 bps Coding methods Modified Huffmann (MH) and special code Power connection...

  • Page 106: Optional Accessory

    Annex Documents Size min. 182 ×148 mm (W x L) max. 216 ×1500 mm Scanning width max. 212 mm Automatic document 20 pages feeder Document thickness 0,05 to 0,15 mm with single page feed 0,08 to 0,13 mm with multiple page feed Scanner Scanner type Image sensor...

  • Page 107: Ce Emblem (Conformity Declaration)

    Annex 10.4 CE emblem (conformity declaration) We hereby certify that the fax machine, and its optional accessories for which this declaration applies, comply with the specifications mentioned below. This declaration is valid within the European Union (EU) only. Product type Desktop fax machine Product name MF1100...

  • Page 108: Index

    Annex 10.5 Index Accessory optional ..................10-5 Activating redial function ..............4-18 Aligning the printer ................2-10 Altering a directory number ...............3-15 Altering one-touch key allocation ............3-10 Altering transmission delay time ............4-14 Ambient requirements .................2-5 Answering machine receiving Receiving faxes answering machine 5-3 Approval symbol ..................1-7 Auflösung einstellen ................4-4 Automatic print-out of delayed transmission report ......4-16...
  • Page 109 Annex Data technical ..................10-4 Date ....................3-7 Delayed document transmission ............4-13 Deleting a directory numberr ............. 3-16 Deleting the allocation of a one-touch key ........3-11 Deleting transmission delay time ............4-15 Dialling a number ................7-3 directory ..................7-4 one-touch ..................
  • Page 110 Annex Document dial and monitor ................4-11 dialling ....................4-7 directory dial .................4-10 one-touch dial ................4-9 redial ....................4-8 sending ..................4-7 Document jam ..................9-4 Documents to be transmitted characteristics ................4-1 Entering numbers into the directory ...........3-14 Error codes in the printed reports ............9-10 External telephone ................5-8 Faxes answering machine ................5-3...
  • Page 111 ..................3-10 deleting ..................3-11 printing a list ................3-12 setting .................... 3-8 storing .................... 3-9 Operation panel of Minoltafax 1100 ............ 2-3 Operational safety ................1-5 Operator call ..................7-6 Optional accessory ................10-5 Overseas transmission ..............4-17...
  • Page 112 Annex Page count ..................4-12 Paper inserting ..................2-11 Paper jam ....................9-5 Parts ....................2-2 Personal safety ..................1-5 Polling ....................5-6 Power cut .....................5-5 Power save mode on ....................8-5 Printed reports error codes ...................9-10 Printer ....................2-10 cleaning ..................9-9 re-aligning ..................9-8 Printer problem memory reception ................5-5 Printing a list of allocated one-touch keys .........3-12 Printing list of directory entry .............3-18 Problems...
  • Page 113 Annex Scrolling through the directory ............3-16 Selected faxes receiving ..................5-4 Sender identification data Setting ................... 3-5 Sending a document ................4-7 Setting date and time ................3-7 Setting delayed document transmission ........... 4-13 Setting page count function .............. 4-12 Setting sender identification data ............
  • Page 114 Annex Technical data ...................10-4 Telephone ....................7-1 Telephone call making ...................7-1 receiving ..................7-2 Time .....................3-7 Transferring a directory entry to a one-touch key ......3-19 Transmission ..................5-6 altering, delayed ................4-14 delayed ..................4-13 delete, delayed ................4-15 print report ..................4-16 setting, delayed ................4-13 Transmission speed ................4-17 Transport rollers cleaning ..................10-2 Trouble-shooting ..................9-1...
  • Page 115 Annex 10-14 MF 1100 Rev. 1.1.1/07.06.99...
  • Page 116 Accessory optional ..................10-5 Activating redial function ..............4-18 Aligning the printer ................2-10 Altering a directory number ...............3-15 Altering one-touch key allocation ............3-10 Altering transmission delay time ............4-14 Ambient requirements .................2-5 Answering machine receiving Receiving faxes answering machine 5-3 Approval symbol ..................1-7 Auflösung einstellen ................4-4 Automatic print-out of delayed transmission report ......4-16 Automatic reception...
  • Page 117 Data technical ..................10-4 Date ....................3-7 Delayed document transmission ............4-13 Deleting a directory numberr ............. 3-16 Deleting the allocation of a one-touch key ........3-11 Deleting transmission delay time ............4-15 Dialling a number ................7-3 directory ..................7-4 one-touch ..................
  • Page 118 Document dial and monitor ................4-11 dialling ....................4-7 directory dial .................4-10 one-touch dial ................4-9 redial ....................4-8 sending ..................4-7 Document jam ..................9-4 Documents to be transmitted characteristics ................4-1 Entering numbers into the directory ...........3-14 Error codes in the printed reports ............9-10 External telephone ................5-8 Faxes answering machine ................5-3 automatic reception ................5-1...
  • Page 119 ..................3-10 deleting ..................3-11 printing a list ................3-12 setting .................... 3-8 storing .................... 3-9 Operation panel of Minoltafax 1100 ............ 2-3 Operational safety ................1-5 Operator call ..................7-6 Optional accessory ................10-5 Overseas transmission ..............4-17...
  • Page 120 Page count ..................4-12 Paper inserting ..................2-11 Paper jam ....................9-5 Parts ....................2-2 Personal safety ..................1-5 Polling ....................5-6 Power cut .....................5-5 Power save mode on ....................8-5 Printed reports error codes ...................9-10 Printer ....................2-10 cleaning ..................9-9 re-aligning ..................9-8 Printer problem memory reception ................5-5 Printing a list of allocated one-touch keys .........3-12 Printing list of directory entry .............3-18 Problems...
  • Page 121 Scrolling through the directory ............3-16 Selected faxes receiving ..................5-4 Sender identification data Setting ................... 3-5 Sending a document ................4-7 Setting date and time ................3-7 Setting delayed document transmission ........... 4-13 Setting page count function .............. 4-12 Setting sender identification data ............
  • Page 122 Technical data ...................10-4 Telephone ....................7-1 Telephone call making ...................7-1 receiving ..................7-2 Time .....................3-7 Transferring a directory entry to a one-touch key ......3-19 Transmission ..................5-6 altering, delayed ................4-14 delayed ..................4-13 delete, delayed ................4-15 print report ..................4-16 setting, delayed ................4-13 Transmission speed ................4-17 Transport rollers cleaning ..................10-2 Trouble-shooting ..................9-1...
  • Page 123 Rev. /...

Table of Contents
