WARNING INDICATORS

If the current measurement is inaccurate due to an out-of-range
condition or a hardware failure, MicroStealth warns you by display-
ing one of the following warning indicators to the left of the nu-
meric level measurement in the marker information area:
Over-range
The signal level is above the measurement range of the
instrument.
Under-range
The signal level is below the measurement range of the
instrument.
Error
A hardware problem exists. If this condition persists, the
unit may need repair.

TILT

TILT mode simplifies the process of balancing an amplifier. TILT
mode can only be accessed by choosing the
NAVIGATOR. A spectral graph of the TILT carriers appears.
44
icon from the
