ZOOMING IN AND OUT

To zoom in on or out from the channel selected by the marker,
press the soft key. A new set of soft keys appear. Use the
soft key to zoom in and the
tion factor is displayed above the graph. Press the
when you have finished.

CHECKING LIMITS

You can verify that the carrier levels are within limits. First, you
need to tell microStealth which test point you are at. This deter-
mines which set of limits are used.
Press the soft key to access the limits submenu. A new set of
soft keys appear.
Press the soft key to sequence through the available test points.
The test point that you have selected is represented in the upper
portion of the screen by one of the following icons:
soft key zoom out. The magnifica-
Subscriber Drop
Ground Block
Tap
User Defined
soft key
41
