Up or down arrows to the left of the video level and DVA numeric
measurement tell you when the limits have been exceeded.
measurement too high
measurement too low
When an adjacent channel error occurs, one of the following
indicators will appear in the lower left-hand area of the marker
information area:
lower adjacent channel level
upper adjacent channel level
both upper and lower adjacent channel levels

MEASUREMENT HOLD

You can freeze the scan measurement at any time by pressing the
SHIFT + keys. The measurement is retained even if the cable
is disconnected from the input port. Notice that the mode icon in
the upper left-hand portion of the screen flashes when the measure-
ment is on hold. Press the SHIFT + keys again to release the
hold. The measurement is not retained when another mode is
selected or the microStealth is shut off.

PRINTING THE SCREEN

You can print the entire screen at any time by pressing the SHIFT
+ keys. A bar graph appears indicating the status of the printout.

STORING A SCAN FILE

Press the SHIFT + keys to store the current scan measurement
into a file. A screen will appear asking you to enter a name for the
file. Once stored, you will be able to recall the file at a later time
and view it on the Scan screen. You will be able to adjust the screen
settings the same as when you are viewing a "live" measurement.
See the section on VIEW mode to find out how to access files that
you have stored.
43
