Fire Hazard
Use 10 gauge solid copper
wire.
Use a UL misted strain relief.
Disconnect
power before making emectrical connections.
Connect
neutral wire (white or center wire) to center
terminal
(simver).
Ground wire (green or bare wire} must be connected
to
green ground
connector.
Connect
remaining
2 suppmy wires to remaining
2 terminals
(go_d).
SecureSy tighten
aH electrical
connections.
Failure to do so can result in death, fire, or
emectdcal shock.
Direct wire cable must match power supply (4-wire or 3-wire)
and be:
[]
Flexible armored cane or nonmetallic sheathed copper cable
(with ground wire), protected with flexible metallic conduit. AII
current-carrying
wires must be insulated.
[]
10-gauge solid copper wire (do not use aluminum).
[]
At least 5 fL (1.52 m) long.
3,
A. External ground conductor screw
B. Tab
C. Terrninalblock cover
D. Hold-down screw
Install ¾" conduit connector into the hole below the terminal
block opening, Connect flexible metallic conduit and tighten
connector screw, Install direct wire cable through the flexible
metallic conduit.
J
A .........
B
4,
A. Conduit connector
B. Dryer cabinet
C. Connector screw
Complete installation following instructions for your type of
electrical connection:
®Four-wire (recommended method)
Three-wire (if four-wire is not available)
Direct Wire,
Four=wire electrical
connection:
to
disconnect
box
Shape ends
of wires into
a hook.
1 (2_5 cm) /
of wires
|_
stripped of |
insulation
I_
5 '_(12,7 cm) _1
Strip 5" (12_7 cm) of outer covering
from end of cable_ Leave green or bare
ground wire at 5" (12J cm). Cut 1½"
(&8cm)from3 remaining w ire&Strip
insulation back1"(2.5cm)_
A. %" conduit connector
B. Neutral (white or center)
C. Ground wire (green or bare)
D. lO-gauge, 3 wire with ground wire in
5, Remove the center terminal block screw,
6, Remove the appliance neutral ground
wire from the external ground conductor
screw, Fasten under center, silver-
colored terminal block screw,
7, Connect the ground wire (green or bare)
of the direct wire cable to the external
ground conductor screw. Tighten screw,
8, Place the hooked end of the neutral wire
(white or center) of the direct wire cable
under the center screw of the terminal
block (hook facing right). Squeeze hook
end together, Tighten screw,
9, Place the hooked ends of the other
direct wire cable wires under the outer
terminal block screws (hook facing right),
Squeeze hooked ends together. Tighten
SCreWS.
10. Insert tab of the terminal block cover into
slot of the dryer rear panel. Secure cover
with hold-down screw.
.... • B
A
_-
A. External g round conductorscrew
B. Applianceneutralgroundwire
C,Centerterminalblock screw
D. Outer terminal b lock screws
E. Neutral(centerwire)
F. Greenor bare ground wire
14
