Whirlpool CEW9100VQ Brochure & Specs

Commercial dryer
Hide thumbs


Advertisement

WHIRLPOOL BRAND
COMMERCIAL DRYERS
PORCELAIN FINISH
Porcelain finish on top with
integrated backsplash, resists
chipping and scratching.
LARGE CAPACITY METERCASE
• L arger coin box for reduced
collections.
• A ccepts coin slides, coin drops, card
readers and can be set up for OPL
non-coin use.
LARGE 6.7 CU. FT.
DRUM CAPACITY
The increased capacity allows for large
loads of clothes to tumble and spread
out, saving you and your customers
drying time and expense.
SIDE SWING REVERSIBLE
OPENING DOOR
• E xtra-large opening
• S ee through door window
and screen
MICROPROCESSOR CONTROLS
• T ime remaining display
• F ront controls for ease-of-use
• D ebit card compatible
• T ime of Day Pricing
AIRFLOW SYSTEM
Whirlpool® commercial dryers blower
system increases air velocity. This
increases efficiency, heating element
life, and improves installation. You can
now vent up to 100 ft. with 3 elbows,
and 1 angled hood for versatility.
4-WAY VENTING
4-Way venting from left or right side,
back or bottom.
LARGE LINT FILTER
Pull-out, 84 square inch steel mesh
lint filter.
1/3 HP MOTOR
1/3 HP motor with overload protection.
COMMERCIAL DRYER
Featuring Microprocessor Controls
Shown with optional pedestal, coin drop and box.
CEW9100VQ –
27" Electric Dryer with Metercase
CGW9100VQ –
27" Gas Dryer with Metercase
Machine accepts the Following Payment
Systems (not included):
- Coin Slide
- Retrofit Coin Drop
- Retrofit Card Reader
- OPL Non-Coin Money Acceptor
And Coin Box Covers
• L arge 6.7 Cu. Ft. Drum Capacity
• F our Roller Suspension with Permanently
Lubricated Bearings
• P ush Button Controls
• L arge Lint Screen (84 Sq. In.)
• B lower Guard Reduces Service Calls
• Front Control Panel 24° Angle
*Call 1-800-NO-BELTS for warranty details
To Locate a Distributor Near You, Please Visit www.whirlpoolcommerciallaundry.com/distributor, or call 1-800-NO-BELTS
• S ide-Swing Reversible Door
• P orcelain Finish on Top with Backsplash
Resists Chipping and Scratching
• F ront-Service Accessibility
• E lectric Heating Element at
5600 Watts 240-Volt
• G as Model Features a 24K BTU Burner
• M otor: 1/3-HP with Built-In Overload
Protector; Centrifugal Switch Turns
Off Heating Element in the Event of
a Broken Belt
3 Year Limited Parts Only Warranty
• M oney Acceptors Sold Separately

Advertisement

Table of Contents
loading

  Related Manuals for Whirlpool CEW9100VQ

  Summary of Contents for Whirlpool CEW9100VQ

  • Page 1 Pull-out, 84 square inch steel mesh lint filter. 1/3 HP MOTOR 1/3 HP motor with overload protection. COMMERCIAL DRYER Featuring Microprocessor Controls Shown with optional pedestal, coin drop and box. CEW9100VQ – 27” Electric Dryer with Metercase CGW9100VQ – 27” Gas Dryer with Metercase Machine accepts the Following Payment Systems (not included): - Coin Slide - Retrofit Coin Drop...
  • Page 2 Whirlpool Corporation • Benton Harbor, Michigan 49022 U.S.A. Dimensions are for planning purposes only. See Whirlpool® INSTALLATION INSTRUCTIONS for full details. MAxIMUM ExHAUST DUCT LENGTH PER NUMBER OF TURNS Number Of 90° Turns Rigid Metal Vent...

This manual is also suitable for:

Cgw9100vq
