Component Identification

Combination terminal block
cover and cable strain relief
clamp
Steel Can-Locking Clamp
(shown deployed)
Internal leads and plug to bring rear
terminal block signal to the loudspeaker's
input connector on the circuit board
Bass reflex
port
Twist-
Assist Face
Mounting
clip (4)
Lock Clamp Alignment
Slot (4 typical) Used
to align face in proper
location when installing
back can
Community Distributed Design Series
Input Terminal
Block
Knockout strain relief on
terminal block cover (with
3/4" and 11"
Knockout
Strain Relief
Hole for 4 mm sheet
metal screw (4
typical)
Loudspeaker In-
put Connector on
circuit board
Figure 18 Component Part Identification (1)
Installation and Operation Manual
conduit installed)
Zinc plated Steel
Can-Locking
Clamp (4)
Twist-Assist Can
Mating Clip (4)
Phillips-head Can-Locking
Clamp Actuator (4)
Drop-Stop
Tab (4)
Zinc plated Steel
Can-Locking
Clamp (4)
Page 18
