HWM70-A
Fuzzy Computeried Automatic

Washing Machine

Please read this manual carefully before using.
Retain it for future reference
Please check if the power receptacle has good earthing
condition before using to guarantee your safety.
The manufacturer will not bear the responsibility for
those risks occurred from not obeying this manual.
Contents
Before using
Names of the parts The 2 cover
the back cover
nd
1
3
5
7
8
9
10
14
14
15
16
17

Advertisement

loading

  Related Manuals for Haier HWM70-A

  Summary of Contents for Haier HWM70-A

  • Page 1: Table Of Contents

    HWM70-A Fuzzy Computeried Automatic Washing Machine Please read this manual carefully before using. Retain it for future reference Please check if the power receptacle has good earthing condition before using to guarantee your safety. The manufacturer will not bear the responsibility for those risks occurred from not obeying this manual.
  • Page 2 Names of the part s Top lid B Detergent box Control panel Level meter Lint filter(Installed by user) Filter cover Control panel film Front control board Pulsator Cabinet Accessories The end connecting to the washing machine Jointer connecting the water inlet hose to the water faucet The end connecting to the water inlet hose jointer...
  • Page 3: Safety Precautions

    Safety precautions Please insert the power cord into special receptacle with rated voltage.Be sure to use single-phase three pins receptacle. The earthing terminal must be earthed reliably.If possible,please adopt electric leakage protector. Earth Do not bend, stretch, twist, bind the power cord by force, or reform it.
  • Page 4 Safety precautions Do not put hand into the rotating tub. It is dangerous even if the rotation speed is slow. Take special care of the children. Keep children away from the washing machine to avoid them climbing on it. Do not put any hot or heavy items (such as the kettle with hot water) on the washing machine.
  • Page 5: Installation And Adjustment

    Safety precautions Please install and adjust the machine according to the requirement of the manual, which is very important for you to operate the machine safely and properly. Install the bottom plate After opening the package, please lean the washing machine gently down on soft items (like towel cloth, blanket, etc.).
  • Page 6: Usage Of The Drain Hose

    Install the lint filter After opening the package, please take out the lint filter from the document bag, install it to the filter cover of inner tub. See to the figure. How to change the direction of the drain hose 1.Dismount the back cover of the washing machine.
  • Page 7: Install The Water Inlet Hose

    Install the water inlet hose Install the water inlet pipe Water faucet, suitable It is required that the front end shall be longer than 10mm. The outlet end surface of the faucet shall be flat and smooth. If not, please file it smooth to avoid leakage. Connection between the water inlet hose jointer and the water faucet 1.Press the lower end of the lock lever and push down the slider.
  • Page 8 Connection between the water inlet hose jointer and the water inlet hose 1 Push down the slider. Plug the water inlet hose into the jointer. 2 Hang the lock lever onto the jointer. Release the slider till a click sound is heard. Check the connection between the water inlet hose jointer and the water faucet 1.Swing the hose gently to check if it is fastened stably.
  • Page 9: Using Process

    1Preparation before washing Pay attention to the followings before washing Check C l e a r t h e the laundries pocket. Take have special out the coins, requirement sand, hairpins on washing etc. A. Check if the laundries are applicable for washing with machine. b.
  • Page 10: Put In The Laundries

    Using process Using process 2 Put in the laundries The capacity of washing and spinning refer to the largest weight of the standard laundries under dry condition that can be washed or spinned in one cycle. Washing quantity for one cycle shall be less than the rated capacity.The largest capacity of this machine is 7.0kg.
  • Page 11: Add The Detergent And Softener

    3 Add the detergent and softener Inlet for concentrated washing powder and detergent Detergent box How to use the whitener Fill water to decided level. Dilute the whitener with container. Pour it slowly into the washing tub. Do not use whitener on laundries with color or print as they are not colorfast.
  • Page 12: Use The Operation Buttons

    4 Use the operation buttons a Description of the function of the operation buttons Mode and meaning of the indicator Flash: indicating the running mode On: indicating the mode about to run Flash rapidly: indicating abnormal situation Balance display If the bulb of the level meter is inside the standard circle, it indicates that the machine is horizontal.
  • Page 13 Digitron During sensing, it displays -- During operation of programs, it displays the remained time (minute) During reserve procedure, it displays the remained reserve time (in hour) In case of abnormal phenomenon, it displays the abnormal symbol (see to Page 16) FUZZY SOAK STANDARD...
  • Page 14 B Steps of using the operation buttons and description of each step. BALANCE DISPLAY 1 Push the POWER ON/OFF button to switch on the power. 2 Push the program button to select suitable automatic program. After switching on the power, the machine will set standard program automatically. To select other automatic program, push the PROGRAM button till the relative indicator is on.
  • Page 15 Attention Even there's no water in the tub, a certain period is required before spin starting. Do not use the SOAK program for the woolen textiles. Separate the laundries that are not colorfast from other laundries in washing. Procedure selection method Times of pushing the Selected procedure SELECT button...
  • Page 16: Close The Top Lid

    Water Level and Time Table of Each Program Wash Water Program (minute) level Standard Night Gentle About About Fast * Total time: including the normal water inlet time and drain time. * Wash time: adjustable according to the water temperature automatically. * Spin time: the time from intermittent running to finishing * The standard and night programs can have SOAK procedure.
  • Page 17: Disposal After Washing

    7 Disposal After Washing Please take off the detergent box and wash it with water 1.How to take it off: Pull it upwards slantingly and gently. 2.How to install: Put it in from the top slantingly, then push it in to the right position. Dismount The filter screen is likely to be blocked by foreign materials and influence water inlet.
  • Page 18: Trouble-Shootinganswers To Questions

    Trouble-shootingAnswers to questions Trouble-shootingAnswers to questions Trouble-shootingAnswers to questions Trouble-shootingAnswers to questions (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company.
  • Page 19: Picking List

    Packing list Name User's manual Lint filter Water inlet hose component Bottom plate Tapping screw Fuzzy logic automatic washing machine Quantity Storage position 1 piece Inside the document bag Inside the document bag 1 piece 2 pieces Inside the accessory bag Between the upper cushion of the 1 piece washing machine package and the upper...
  • Page 20: Specifications

    Max water consumption Water inlet pressure Rated washing power Rated spinning power Weight Dimensions (mm) HWM70-A 220V ~ 60Hz 7.0kg 1/23L, 2/30L, 3/34L, 4/40L, 5/44L, 6/49L, 7/53L, 8/57L, 9/61L, 10/66L About 186L (the highest water level, standard program) 0.03MPa-0.78MPa (when water temperature is 70 ~90 , the water inlet pressure of hot water shall not exceed 0.4MPa)
