Haier HWM70-98 User Manual

Computerized full-auto washing machine
Hide thumbs

Advertisement

Quick Links

HWM70-98
Computerized Full-auto
Washing Machine
Please read this manual carefully before using.
Retain it for future reference
Please check if the power receptacle has good earthing
condition before using to guarantee your safety.
The manufacturer will not bear the responsibility for
those risks occurred from not obeying this manual.
Contents
Names of the parts..........................The 2nd cover
Safety precautions...............................................1
Installation and adjustment......... ........................3
Install the water inlet hose....................................5
Preparation before washing.................................7
Put in the laundries..............................................8
Use of the detergent...........................................9
Use the operation buttons.................................10
Close the top lid................................................14
Finish washing..................................................14
Disposal after washing......................................15
Packing list................................................17
Specification table
The back cover

Advertisement

loading

  Related Manuals for Haier HWM70-98

  Summary of Contents for Haier HWM70-98

  • Page 1: Table Of Contents

    HWM70-98 Computerized Full-auto Washing Machine Please read this manual carefully before using. Retain it for future reference Please check if the power receptacle has good earthing condition before using to guarantee your safety. The manufacturer will not bear the responsibility for those risks occurred from not obeying this manual.
  • Page 2: Before Using

    Names of the parts Honourable users: Thank you for choosing our products. Our products integrate high-tech, precision, frontier science .To facilitate using it, please read this manual carefully and operate this machine according to it. Top lid components Inner cover components Detergent box Control panel Outer tub cover...
  • Page 3: Safety Precautions

    Safety precautions Please plug the power plug on special receptacle. Be sure to use three-pins power receptacle. Ensure that the earthing prong of the power receptacle is earthed reliably. Use leakage protector if possible. Do not bend ,extend,twist,bind by force.Do not press or nip it with weight. Keep the pin of the power plug clean,if the power plug is polluted with dust,please wipe with dry cloth carefully.
  • Page 4 Safety precautions Do not stretch hands into the working machine. It is dangerous even if the rotation is slow. Take special care of the children. Do not put any hot or heavy items (such as the kettle with hot water) on the washing machine The appliance is not instruct for use of young children of infirm persons without supervision.Young children should be...
  • Page 5: Installation And Adjustment

    Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Install the inner cover components 1.Open the top lid of the washing machine. 2.Put the inner cover component on the outer tub cover, aiming the inner cover shaft to the installation hole of the corresponding outer tub cover shaft groove.
  • Page 6: Usage Of The Drain Hose

    How to change the direction of the drain hose 1.Lean the machine down gently with the front surface facing the ground. Loosen the eight screws by a cross screwdriver. Back Front 2.Pull out the drain hose from the groove at the left side. Use groove at this side after direction changing...
  • Page 7: Install The Water Inlet Hose

    Install the water inlet hose Confirm the water faucet water faucet, suitable The exit end face of the faucet It is required that the front end shall be longer than 10mm. The exit end face of the faucet shall be flat and smooth. If not please file it to avoid leakage. Connection between the water inlet hose jointer and the water faucet 1.Press the lower end of the lock lever and push down the slider.
  • Page 8 Connection between the water inlet hose and the washer 1.Do not take off the water absorption cushion. Please check if the cushion is dropped or damaged before each usage. If it happens please contact our after-sale department immediately. 2 Put the nut of the water inlet hose on the valve jointer.
  • Page 9: Using Process

    1 Preparation before washing Pay attention to following before washing Check C l e a r t h e Pay attention to followings before washing the laundries the laundries pocket. Take has special out the coins, requirement sand, hairpins on washing etc.
  • Page 10: Put In The Laundries

    2 Put in the laundries Reference weight of the laundries: working suit up,down cotton,about 1120g blanket cotton,about 900g pajamas about 200g shirt cotton,about 300g undershirt cotton,about 180g The capacity of washing and spinning of the machine refer to the largest weight of the standard laundries under dry condition that can be washed or spinning in one time.
  • Page 11: Usage Of The Detergent

    2 Usage of the detergent Washing powder inlet entrance Softener inlet entrance How to use the whitener Fill water to decided level .Dilute the whitener with container. Pour it slowly into the washing tub. Avoid using whitener on laundries with colour or pattern as they are prone to lose colour.
  • Page 12: Use The Operation Buttons

    4 Use the operation buttons Description of the function of the buttons Mode and meaning of the VFD indicator the frame of the indicator is on : indicate the program about to run, or indicate the selected mode SOAK button WASH button Push the SOAK button Push the WASH button...
  • Page 13 Child lock function This function is used to protect the children and prevent them from changing the washing procedure. Push and hold the WATER LEVEL button and SPIN button, then push down the POWER ON/OFF button. The digitron displays CL . You can continue setting desired washing procedures.
  • Page 14 Steps of using the operation buttons and description of the steps Minutes Times Minutes Push the "POWER ON/OFF " button to switch on the power. Push the "PROGRAM" button After switching on the power, the machine will set normal program automatically. To select other automatic program, push the "program"...
  • Page 15 After switching on the power, the washing machine will set to common program including"wash, rinse, spin "automatically. To select other procedures, push the " SOAK"," WASH", " RINSE" or "SPIN" button to select the time of soak,wash and spin, and the times of rinse. After switching on the power, if you push one of the button among "WASH", "RINSE"and"SPIN", the digitron of the former procedures will turn off automatically.
  • Page 16: Close The Top Lid

    Push the "START/PAUSE" button 5 Close the lid As the top lid opened ,the Washer will automatically give an alarm and stop running , exclusively during supplying water and rinsing. 6 Finish washing After finishing wash it'll switch off the power automatically.
  • Page 17: Disposal After Washing

    Disposal after washing After using, please clean the lint and foreign materials of the lint filter etc. in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. Clean the detergent box and set it on the control panel seat.
  • Page 18: Trouble Shooting Answer To Question

    Trouble-shooting Answer to question (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company.
  • Page 19: Packing List

    Packing list Components of the water inlet hose Inner cover component Bottom plate Computerized Automatic washing machine Inside the accessory bag Between the upper cushion of the washing machine package and the upper seal of the package carton...
  • Page 20 Water level/Water quantity (about) Max water consumption Water Injection pressure Rated washing input power Rated spinning input power Weight Overall dimension HWM70-98 220V -240V~ 50Hz 7.0kg 1/18L 2/24L 3/30L 4/36L 5/42L 6/48L 7/54L 8/60L 9/66L 10/70L About 120L (Highest water level; Normal program) 0.03MPa~0.78MPa...
