Finish the Installation

To finish the installation:
1. Close the computer.
2. Connect the computer monitor's video cable to the blue video output
port on the Intense 3D Pro 3410 card. See the following figure.
If a computer monitor has no built-in video cable, use a shielded
video cable with a 15-pin (D-sub) video connector at one end for
the video output port on the card and the appropriate connectors at
the other end for the video input port on the computer monitor.
NOTE
Monitor input ports are usually D-sub or Bayonet Nut Connect
(BNC) connectors. Shielded cables usually have a ferrite core (a
box- or cylinder-shaped attachment) near each end to reduce
interference with radio frequencies.
3. Turn on the computer. The video display starts in VGA mode.
4. Install the Intense 3D Pro Graphics video display driver as
instructed in Chapter 4, "Installing the Software."
11
