1.
The ambient temperature should be between 32 and
104 degrees Fahrenheit (0 to 40 degrees Celsius).
2.
The relative humidity should be less than 90 percent,
non-condensing.
3.
Surrounding electrical devices should not exceed the
electromagnetic field (RFC) standards for IEC 801-3,
Level 2 (3V/M) field strength.
4.
Make sure that the equipment receives adequate
ventilation. Do not block the ventilation holes on each
side of the switch or the fan exhaust port on the side or
rear of the equipment.
5.
The power outlet should be within 1.8 meters of the
switch.

Connecting to Power

1.
This Converter is a plug-and-play device.
2.
Connect the supplied AC to DC power adaptor with a
power voltage of 7.5Vdc/1.5Amp to the DC-Jack on
the converter, and then attach the plug into a standard
AC outlet.
ATTENTION!
Please be sure that the other end will be
connected to a switch that set to Full Duplex (forced mode)

Installing in a Chassis

The Converter can be fit into any of the expansion slots
on a special designed chassis.
4
