S
T
ETUP
C
ONVERTER
As with any electric device, you should place the equipment where it
will not be subjected to extreme temperatures, humidity, or
electromagnetic interference. Specifically, the site you select should
meet the following requirements:
• The ambient temperature should be between 32 and 104 degrees
Fahrenheit (0 to 40 degrees Celsius).
• The relative humidity should be less than 90 percent, non-
condensing.
Surrounding
electromagnetic field (RFC) standards for IEC 801-3, Level 2 (3V/M)
field strength.
• Make sure that the equipment receives adequate ventilation. Do not
block the ventilation holes on each side of the media converter or the
fan exhaust port on the side or rear of the equipment.
• The power outlet should be within 1.8 meters of the switch.
C
ONNECTING THE POWER
Step 1: This Converter is a plug-and-play device.
Step 2: Connect the supplied AC to DC power adaptor with a power
voltage of 7.5Vdc/1.5Amp to the receptacle on the rear panel of the
converter, and then attach the plug into a standard AC outlet with a
voltage range from 100 to 260 Vac.
DMC-1910 S
HE
electrical
INGLE
devices
should
3
F
M
IBER
EDIA
not
exceed
the
