1.
The ambient temperature should be between 32
and 104 degrees Fahrenheit (0 to 40 degrees
Celsius).
2.
The relative humidity should be less than 90
percent, non-condensing.
3.
Surrounding electrical devices should not exceed
the electromagnetic field (RFC) standards for
IEC 801-3, Level 2 (3V/M) field strength.
4.
Make sure that the equipment receives adequate
ventilation. Do not block the ventilation holes on
each side of the switch or the fan exhaust port on
the side or rear of the equipment.
5.
The power outlet should be within 1.8 meters of
the switch.

Connecting to Power

1.
This Converter is a plug-and-play device.
Connect the supplied AC to DC power adaptor
2.
with a power voltage of 7.5Vdc/1.5Amp to the
DC-Jack on the converter, and then attach the
plug into a standard AC outlet

Installing in a Chassis

The Converter can be fit into any of the expansion slots
on a special designed chassis.
First, install the converter onto a carrier supplied with
.
4
