1. This Converter is a plug-and-play device.
2. Connect the supplied AC to DC power adapter with a power voltage
of 5Vdc/1Amp to the DC-Jack on the converter, and then attach the
plug into a standard AC outlet.
S
S
LIDING
WITCH
There is a sliding switch for duplex mode setting for fiber port.
I
C
NSTALLING IN A
HASSIS
The Converter can be fit into any of the expansion slots on DMC-1000
chassis.
First, install the converter onto a carrier supplied with the chassis:
3
