Rascal R600 Scooter Owner's Manual
Components
Rascal 600 Series Scooters consists of the following major components, as shown in Illustration 1. You
should familiarize yourself with the location and general functioning before proceeding.
MODEL 600C
MODEL 600F
CONTROLS
TILLER
SEAT
WHEELS
&
TIRES
POWER CHAIR
4-WHEEL
FRONT END
FRONT END
MODEL 600T
DASH/HANDLEBAR
REAR
SECTION
DRIVETRAIN
3-WHEEL
FRONT END
COVERS
19271200/1
Illustration 1 — Major Components
EMC Part: 19271200 • Rev. 03 • 06/01/2003
