Rascal R6 300 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Owner's Manual
Model R6 300
ELECTRIC
MOBILITY
EMC Part: 19271200
World Leader in Personal Independent Mobility
Rev. 01 • Date 02/28/03
1 Mobility Plaza, Sewell, NJ 08080

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R6 300 and is the answer not in the manual?

Questions and answers

Related Manuals for Rascal R6 300

Summary of Contents for Rascal R6 300

  • Page 1 Owner’s Manual Model R6 300 ELECTRIC MOBILITY EMC Part: 19271200 World Leader in Personal Independent Mobility Rev. 01 • Date 02/28/03 1 Mobility Plaza, Sewell, NJ 08080...
  • Page 2 Only the patented ConvertAble Rascal can be easily changed into a 3-wheeled or 4-wheeled scooter, or indoor PowerChair vehicle. Your ConvertAble Rascal Scooter has been thoroughly tested and will give you years of good service and pleasure, providing you follow the instructions and precautions in this manual.

  • Page 3: Table Of Contents

    Contents Title Page Safety Information ........................1 Important Information Regarding Electromagnetic Interference (EMI) ....... 2 Getting to Know Your Rascal Scooter ..................3 Model Designation ........................3 Components ..........................4 Illustration 1 — Major Components ................4 Controls ........................... 6 Illustration 2 —...
  • Page 4 Rascal R6 300 Scooter Owner’s Manual Maintenance and Servicing .....................23 Preventative Maintenance ....................23 Battery Connections .......................23 Rear Wheel Removal ......................23 Front Wheel Removal .....................23 Tire Tread Wear .......................24 Seat Post Lubrication .....................24 Caster Wheels .........................24 Clock Battery ........................24 Electrical Connections ....................24 Hardware Inspection ......................24...
  • Page 5 © 2004 Electric Mobilty Corp. Electric Mobility ® Rascal® and ConvertAble® are registered trademarks of Electric Mobilty Corp. No liability is assumed with respect to the use of any information contained in this publication. While every precaution has been taken in the preparation of this publication, Electric Mobilty Corp., assumes no responsibility for errors or omissions nor is any liability assumed for...

  • Page 6: Safety Information

    Rascal R6 300 Scooter Owner’s Manual Safety Information Read and understand these Warnings and the entire manual before using your Scooter. WARNING! Failure to follow these instructions may result in serious or fatal injury to the user or damage to the vehicle.

  • Page 7: Important Information Regarding Electromagnetic Interference (Emi)

    Rascal R6 300 Scooter Owner’s Manual Important Information Regarding Electromagnetic Interference (EMI) It is very important that you read this information regarding the possible effects of electromagnetic interference (EMI) on your scooter. Electromagnetic interference (EMI) refers to the effects that outside sources of electromagnetic energy (radio and television broadcasts, CB radios, garage door openers, cellular telephones, etc.) might have on the control systems of your scooter.

  • Page 8: Getting To Know Your Rascal Scooter

    Rascal R6 300 Scooter Owner’s Manual Getting to Know Your Rascal Scooter Congratulations on your purchase of a Rascal 600 Series scooter, the latest in easy, convenient personal mobility from Electric Mobility Corp. Before attempting to use your scooter, we recommend you read this section first to learn about your new scooter.

  • Page 9: Components

    Rascal R6 300 Scooter Owner’s Manual Components Rascal R6 300 Series Scooters consists of the following major components, as shown in Illustration 1. You should familiarize yourself with the location and general functioning before proceeding. MODEL R6 300 SEAT DASH CONTROLS...
  • Page 10 Rascal R6 300 Scooter Owner’s Manual 4-Wheel Front End The Model R6 300 uses a 4-wheel front end to provide the maximum in stability over a variety of outdoor terrains. Sturdy, independent front suspension provides greater comfort and a smoother ride.

  • Page 11: Controls

    These accessories are available separately and come with complete instructions for installation and use with your vehicle. Contact your Customer Service representative for further information. Controls The Rascal Scooter includes the following controls used for its operation. These controls are shown in Illustration 2. FUEL GAUGE...
  • Page 12 Rascal R6 300 Scooter Owner’s Manual Fuel Gauge Indicates the charge level of your batteries. If the 20 22 24 needle goes into the red area, the batteries need to be charged as soon as possible. If the needle is all the way to the right side of the green area, the batteries are fully charged.
  • Page 13 Rascal R6 300 Scooter Owner’s Manual Hazard Switch The Rascal includes Hazard Indicators to alert others that you’ve stopped or require assistance. Pressing the Hazard Switch flashes front and rear amber lamps. Pressing again turns lamps off. Seat Lift Switch (Optional) If your scooter is equipped with optional seatlift, you can use this switch to raise and lower the seat automatically.
  • Page 14 “On.” Turning it to the left (key upright) turns power “Off.” A set of 2 keys are supplied with each Rascal Scooter. We recommend that you put one away in a secure place in case you lose your operating key.

  • Page 15: Initial Setup And Adjustments

    Other controls mounted on the tiller operate exactly as controls on the dash. Initial Setup and Adjustments Before using your Rascal scooter, you should perform the following initial setup and adjustments to ensure that you are as comfortable as possible. The setup and adjustments include: •...

  • Page 16: Illustration 3 - Ammeter

    Rascal R6 300 Scooter Owner’s Manual Use the following to charge batteries of your Rascal scooter. 1. Park the vehicle near a 3-Prong Grounded Electrical Receptacle. WARNING! Use of a non-grounded receptacle could result in an electrical shock. 2. Lift the trunk lid and remove the power cord from the trunk area.

  • Page 17: Adjustments

    Rascal R6 300 Scooter Owner’s Manual Adjustments Your scooter has been pre-adjusted to meet most customers’ needs, however your scooter includes several adjustments to adapt it to specific height and width requirements. These adjustments include: • Adjusting the Seat (armrest width and armrest/backrest angles) •...

  • Page 18: Adjusting Backrest Angle

    Rascal R6 300 Scooter Owner’s Manual Adjusting Backrest Angle The seat is designed with five available backrest settings (90°, 95°, 100°, 105° and 115°) to allow you to adjust the angle of the back of your seat. The 90° setting provides the most upright position and the 115°...

  • Page 19: Adjusting The Handlebar Assembly And Dash Position

    Dash and handlebar assembly adjustments are shown in Illustrations 7 and 8. Adjust dash angles so that your elbows can rest on the armpads while you operate your Rascal and you can see ADJUSTMENT the dash controls.

  • Page 20: Dashboard Clock

    Rascal R6 300 Scooter Owner’s Manual Dashboard Clock Your Rascal R6 300 Series Scooter comes with a removable, battery-powered, quartz clock that mounts directly in the dashboard of the scooter. This clock is shipped separately to allow you to set it to your local time before installing in the dashboard.

  • Page 21: Seat Post Height Adjustment

    Rascal R6 300 Scooter Owner’s Manual Seat Post Height Adjustment If the scooter does not include the electric seat lift, the seat height can be adjusted manually. The Seat Post tube has 3 holes; this makes it adjustable so you can set the seat height that is most comfortable for you.

  • Page 22: Using The Scooter

    Rascal R6 300 Scooter Owner’s Manual Using the Scooter Once you are familiar with the components, controls, charged the batteries, and any height or width adjustments, you can follow these instructions in this section to operate it. • Transferring On & Off •...

  • Page 23: Driving

    Rascal R6 300 Scooter Owner’s Manual Driving Once seated on your Rascal scooter, driving is simple. Set Speed Dial to desired speed range. Use the Engager Lever to move forward (squeeze right side) or reverse (squeeze left side) Steer in the desired direction.

  • Page 24: Illustration 11 - Brake Release Lever

    Rascal R6 300 Scooter Owner’s Manual WARNING! Never sit in vehicle if it is in “freewheel” mode on an incline. PUSH POSITION DRIVE POSITION 19271200/12 Illustration 11 — Brake Release Lever When finished pushing the vehicle, place the lever back into the ‘DRIVE’ (down) position to prevent the vehicle from rolling.

  • Page 25: Vehicle Disassembly & Re-Assembly

    Rascal R6 300 Scooter Owner’s Manual Vehicle Disassembly & Re-Assembly Your vehicle has been designed for easy disassembly for convenient transporting and storage. The sequence listed below is for complete disassembly of your vehicle. Assembly is accomplished by reversing these steps. You may only need to disassemble a portion of the vehicle depending on your space requirements.

  • Page 26: Quick Disconnect Drive Train (Qddt) Removal

    Rascal R6 300 Scooter Owner’s Manual Quick Disconnect Drive Train (QDDT) Removal You can remove the drivetrain assembly according to the following. Drivetrain removal is shown in Illustration 12. QUICK-DISCONNECT LIFT STRAIGHT UP PINS ROTATE OUT DRIVETRAIN POWER HARNESS 19271200/16 Illustration 12 —...

  • Page 27: Transporting Your Scooter

    By Airplane — To transport your unit on an airplane, we recommend that you call your airline at least 24 hours in advance to ensure that they are aware of your scooter. Your Rascal batteries are approved for airline travel. Ask specifically where and with whom you should drop the unit off and where and with whom you should retrieve it at your destination.

  • Page 28: Maintenance And Servicing

    • Troubleshooting • Factory Return Procedures Your Rascal scooter requires only minimal maintenance and by setting time aside each month for careful inspection and checking items included in this section, you can be assured of a long, useful life of your vehicle.

  • Page 29: Tire Tread Wear

    Rascal R6 300 Scooter Owner’s Manual Tire Tread Wear Measure tire tread depth. If less than 1/32", it is recommended you replace the tire. Seat Post Lubrication The seat should rotate freely. Clean and lubricate the top of the seat post and the inside of the seat base attached to the seat.

  • Page 30: Polishing

    Rascal R6 300 Scooter Owner’s Manual Polishing Polish all plastic components to help protect them from scratches and a dull finish. This can be done by using a non-abrasive auto polishing material available at your local automotive parts dealer or local department store (automotive section).

  • Page 31: Troubleshooting

    Rascal R6 300 Scooter Owner’s Manual Troubleshooting This table is only a guide to aid you in getting your vehicle operating, should you have any problems. If you are unable to get your vehicle operating, call either Electric Mobility Customer Service toll free number located at the front of this manual or your local Authorized Service Center.

  • Page 32: Controller Troubleshooting

    Rascal R6 300 Scooter Owner’s Manual Controller Troubleshooting The controller used in the scooter includes internal diagnostics programming used to identify and troubleshoot problems and/or faults. When this diagnostics programming detects a problem or fault, the Status Indicator lamp on the dash flashes consecutively up to nine times to identify the problem.

  • Page 33: Limited Warranty Information

    Rascal R6 300 Scooter Owner’s Manual Limited Warranty Information Electric Mobility Corporation guarantees for the original purchaser and FSS ordering activities that are the original purchasers of our products, that the frame of the vehicle will be free from manufacturers defects in materials and workmanship for the lifetime of the vehicle providing it is properly used and maintained in accordance with the owner/operator manual.
  • Page 34 Rascal R6 300 Scooter Owner’s Manual a. Battery fluid spillage or leakage. b. Abuse, misuse, accident or negligence. c. Improper operation, maintenance or storage. d. Commercial use or use other than normal. e. Repairs and/or modifications made to any part without specific consent from Electric Mobility Corporation.

  • Page 35: Application Certification Standards

    Rascal R6 300 Scooter Owner’s Manual Application Certification Standards The supplier must meet and must certify in its application for billing privileges that it meets and will continue to meet the following standards: Operates its business and furnishes Medicare-covered items in compliance with all Federal and State licensure and regulatory requirements;...

  • Page 36: Specifications

    Rascal R6 300 Scooter Owner’s Manual Specifications Designation Model R6 300 Model R6 300 HD Overall Length 46” (116.8 cm) 48.75” (123.8 cm) Width 24.5” (62.2 cm) 25” (63.5 cm) Turning Radius 62” (175.5 cm) 66.5” (169 cm) 14 ° (340 lb.) 14 °...

  • Page 37: Index

    Rascal R6 300 Scooter Owner’s Manual INDEX Adjusting Armrest Angle, 12 Installing the Clock, 15 Adjusting Armrest Width, 12 Keyswitch, 9 Adjusting Backrest Angle, 13 Light Switch, 9 Adjusting Seat Swivel Position, 13 Limited Warranty Information, 28 Adjusting the Handlebar Assembly and Dash...
  • Page 38 Electric Mobility is a family owned and operated company with its headquarters in Southern New Jersey. The company has a proud tradition of innovation and achievement that began in 1974 with company founder Francis Flowers. Today, Electric Mobility employs over 450 men and women and maintains a sales and service network that reaches all 50 states and 22 foreign countries.
