3-Wheel Front End
4-Wheel Front End
Chair Front End
Controls
Rear Section
Covers
Seat
Dash/Handlebar
Rascal R600 Scooter Owner's Manual
The Model 600T uses a 3-wheel front end for tight, sure-footed turning
with a maximum of maneuverability. The steering handlebar is
connected directly to the front fork for easy, yet precise steering control.
Large, side-mounted casters provide persistent stability.
The Model 600F uses a 4-wheel front end to provide the maximum in
stability over a variety of outdoor terrains. Sturdy, independent front
suspension provides greater comfort and a smoother ride.
The Model 600C includes a Chair Front End that allows the 3-wheel and
4 wheel model scooters to be used as an indoor model by replacing the
scooter front section with the Chair sized front end. In place of the 3-
wheel and 4-wheel handlebar and dash, the Model 600C includes a left
or right hand tiller that provides complete one handed steering control
with fingertip operation for forward or reverse movement.
An internal, on-board, digital controller provides all major driving and
operating functions directly from the dash of the handlebar or tiller. Self-
Diagnostics provide troubleshooting information to detect electrical
problems or faults. Additionally, the controller includes a power save
feature and will shut down automatically in order to conserve battery
power when not operated for a set period of time. The scooter can be
turned on again by turning the ON/OFF keyswitch from on to off and
then on again.
A common rear section provides a central, easily accessible location for
controls, charger, wiring components, while serving as the mounting
point for the removable quick disconnect drivetrain.
Internal components are protected by a plastic rear cover of the scooter.
The rear cover can be removed for access to charger, controller, etc.
Charger, controller, and batteries are also protected by an internal cover
inside the rear plastic cover.
For super comfort, all Rascals include a padded, removable, swivel seat
with adjustable back angle and "flip-up" armrests. As an option, the seat
is mounted to an electrically operated seat lift to raise and lower the
seat 5" using controls mounted in the dash/tiller. A manually adjustable
seat post can also be supplied. A spring-loaded lever mounted on the
base of the seat allows it to be rotated and locked in position at each
45° increments.
The Model 600T and 600F are steered and operated by a removable
handlebar and dash assembly. The Model 600C is steered by a Tiller
assembly. Operation of the individual control components are described
in the "Controls" section of this manual (see page 7).
EMC Part: 19271200 • Rev. 03 • 06/01/2003
5
