REAR PANEL CONTROLS AND CONNECTIONS

1. CARRYING INSET:
moving or carrying the REDCAT.
2. 8-BAND GRAPHIC EQUALIZER:
controls adjust the levels of the various audio
frequencies. This allows the installer to properly equalize the system to
produce optimum sound quality.
3. COMPUTER AUDIO INPUT:
audio source into this jack.
4. DVD/VCR AUDIO INPUT:
this mono input jack.
Plug the power supply (24 V/1.75 A) into this jack.
5. DC INPUT:
Helpful Hint
Before adjusting the graphic equalizer refer to the intial set-up on page 18. Sometimes
fine-tuning is required to eliminate feedback.
Fine-tuning the Graphic Equalizer:
up and flip down the EQ cover door.
1. Slide
the room listening for feedback
2. Walk
(squealing).
the 2K5 and/or 4K sliders if a high-
3. Lower
pitched ring is present.
the 400 and/or 700 sliders if a low-
4. Lower
pitched ring is present.
5. Reduce volume if feedback is still present.
1
2
Cutaway grip for
The sliding
Plug the 3.5mm cord from computer or other
Plug the RCA stereo cord from any DVD or VCR into
R E D C A T U s e r M a n u a l
3
4
REDCAT User Manual | 4
5
